| What's in the box |
Printer: HP DesignJet T1700dr 44-in PostScript Printer, printheads, ink cartridges, printer stand, spindles (x2), setup poster, introductory information, warranty, power cords, label kits; Scanner: HP SD Pro Scanner, stand, touchscreen (panel PC), quick reference guide, setup poster, copy/scan software, documentation software, Ethernet cables (x2), power cords |
| Power consumption |
Printer: < 100 W (printing); < 24 W (ready); < 1 W (< 6.5 W with embedded Digital Front End) (sleep); 0.35 W (off); Scanner: 47 W (scanning); 32 W (ready); 1.8 W (sleep) |
| Power |
Printer: Input voltage (auto ranging) 100-240 V (±10%), 50/60 Hz (±3 Hz), 2 A max; Scanner: Input voltage (auto ranging): 100-240 V (±10%), 50/60 Hz, 5 A max |
| Registration required |
No |
| Cartridge volume |
130 ml; 300 ml |
| Ink drop |
6 pl |
| Ink types |
Dye-based (C, M, Y, PK, G); pigment-based (MK) |
| Number of cartridges |
6 |
| Print Cartridges/Bottle, Number |
6 (cyan, magenta, yellow, photo black, matte black, gray) |
| Print cartridge/bottle volume |
Cyan, magenta, yellow, photo black, matte black, gray (300 ml); Cyan, magenta, yellow, photo black, matte black, gray (130 ml) |
| Print head nozzles |
2112 each color |
| Print heads |
3 universal printheads, 2 colors each |
| Primary applications |
Office documents and presentations; Engineering and construction documents; Maps |
| Sub brand |
DesignJet |
| Electromagnetic compatibility |
Printer: Compliant with Class B requirements, including: USA (FCC rules), Canada (ICES), EU (EMC Directive), Australia (ACMA), New Zealand (RSM), China (CCC), Japan (VCCI), Korea (KCC), South Africa (SABS); Scanner: Compliant with Class A requirements, including: USA (FCC rules), Canada (ICES), EU (EMC Directive), Australia (ACMA), New Zealand (RSM), Japan (VCCI), Korea (KCC), China (CCC) |
| Safety |
Printer: USA and Canada (CSA certified); EU (LVD and EN 60950-1 compliant); Russia, Belarus, Khazakstan (EAC); Singapore (PSB); China (CCC); Argentina (IRAM); India (BIS); Scanner: USA and Canada (CSA certified); EU (LVD and EN 60950-1 compliant); Russia, Belarus, Khazakstan (EAC); China (CCC) |
| Accessories |
HP DesignJet 44-in Spindle Q6709A; HP DesignJet 3-in Core Adapter CN538A; HP USB 3.0 to Gigabit LAN Adapter N7P47AA |
| Connectivity, optional |
Printer: HP USB 3.0 to Gigabit LAN Adapter |
| Connectivity, standard |
Printer: Ethernet, Fast Ethernet, Gigabit Ethernet, 10/100/1000Base-T Ethernet (802.3, 802.3u, 802.3ab); USB Type-A host port; Scanner: Gigabit Ethernet (1000Base-T); Hi-Speed USB 3.0 certified |
| HP ePrint capability |
Yes |
| Network ready |
Standard |
| Security features |
HP Secure Boot, HTTPS, Secure-IPP, IPsec/Firewall, Certificates management, 802.1X, TLS 1.0/1.1/1.2, HP Web Jetadmin compatible, HP JetAdvantage Security Manager compatible, self-encrypting HDD, PIN printing |
| Copier settings |
Type of original; image crop and align preview; lightness; saturation and RGB controls; white point and black point adjust; sharpen/blur; mirror copy; enlarge/reduce; paneling; tiling; nesting; accounting; batch; multipage PDF generation |
| Copies, maximum |
1000 |
| Acoustic pressure emissions |
Printer: 45 dB(A) (operating), 32 dB(A) (idle), |
| Non-Operating Humidity Range |
0 to 90% RH |
| Operating humidity range |
20 to 80% RH |
| Operating temperature range |
5 to 40ºC |
| Country of origin |
China(, BCD, ABG, B1K) |
| Plus |
Bundled scanner and printer. |
| Why to buy |
Work productively with the HP DesignJet SD Pro MFP. Capture documents quickly and in detail with the high-speed scanner. Simplify operation and boost workflows with dual rolls and smart switching. Handle complex files easily and securely. |
| Headline |
Enjoy a smooth scanning/printing experience. Two roles and smart switching let you print seamlessly on different paper types and sizes. Manage complex files with ease while also protecting your devices and data with advanced security features. |
| Key selling point |
Rely on Adobe PDF drivers to free up your computer immediately after sending to print—even for complex files. |
| Image legal disclaimer |
Product image may differ from actual product |
| Product logos |
Adobe PDF Print Engine 4; Adobe PostScript 3; ENERGY STAR; EPEAT Silver; Gold IPv6 Ready; PANTONE* Digital Color; Windows 10 Compatible |
| Monthly printed pages |
Very frequently |
| Taxonomy |
Large Format Printers/ Plotters |
| Segment |
Business |
| Non-printable area (cut-sheet) |
3 x 17 x 3 x 3 mm |
| Non-printable area (roll media) |
3 x 3 x 3 x 3 mm |
| Maximum optical density (black) |
2.15 maximum black optical density (6 L*min) |
| Functions |
Print, copy, scan |
| Line accuracy |
±0.1%[2] |
| Model size |
1118 mm |
| Guaranteed minimum line width |
0.06 mm (ISO/IEC 13660:2001(E))[3] |
| Printer drivers included |
Printer: Raster drivers for Windows and macOS; PostScript and PDF Windows drivers and macOS PostScript driver; Scanner: Windows drivers for compatible HP DesignJet Printers |
| Print languages |
Adobe PostScript 3, Adobe PDF 1.7 ext 3, HP-GL/2, TIFF, JPEG, URF, CALS G4 |
| Theoretical minimum line width |
0.02 mm (PDF addressable @ 1200 dpi) |
| Maximum roll diameter |
5.3 in |
| Media thickness |
Up to 31.5 mil |
| Printer Applications |
Architecture; Maps; Presentation graphics |
| Recommended media |
C6810A HP Bright White Inkjet Paper (FSC® certified) (Recyclable) 914 mm x 91.4 m (36 in x 300 ft);C6569C HP Heavyweight Coated Paper (Recyclable) 1067 mm x 30.5 m (42 in x 100 ft);Q6581A HP Universal Instant-dry Satin Photo Paper (FSC® certified) (Recyclable) 1067 mm x 30.5 m (42 in x 100 ft);Q1406B HP Universal Coated Paper (FSC® certified) (Recyclable) 1067 mm x 45.7 m (42 in x 150 ft) |
| Roll external diameter |
135 mm |
| Roll maximum input |
2 |
| Roll size |
Up to 44 in |
| Product Disclaimer |
Certain HP printers are intended to work only with cartridges that have a new or reused HP chip or electronic circuitry. These printers use dynamic security measures to block cartridges using a non-HP chip or electronic circuitry. Periodic firmware updates will maintain the effectiveness of these measures and block cartridges that previously worked. Reused HP chips and electronic circuitry enable the use of reused, remanufactured, and refilled cartridges. |
| Dynamic security |
Dynamic security enabled printer |
| Overview |
Quickly print and scan documents, maps, and drawings with the HP DesignJet SD Pro MFP. See high-quality results at fast speeds. Accelerate workflows and handle even the most complex files with this reliable, secure printer. |
| Photo (product photo, jpg, 190x170) |
Printers and Multifunction/HP-Designjet-SD-Pro-MFP_190x170.jpg |
| Photo (product photo, jpg, 400x400) |
Printers and Multifunction/HP-Designjet-SD-Pro-MFP_400x400.jpg |
| Photo (product photo, jpg, 70x100) |
Printers and Multifunction/HP-Designjet-SD-Pro-MFP_70x100.jpg |
| Company |
HPI |
| Code name |
Juno bundle |
| Product long name |
HP DesignJet SD Pro 44-in MFP |
| Product long name specifications |
HP DesignJet SD Pro 44-in MFP - Print: 10 m²/hr (coated), A1 plain paper line drawing: 28 sec/page, 103 A1 prints per hour (economode), Up to 2400 x 1200 optimized dpi (colour); Standard Memory: Printer: 32 GB (virtual); Scanner: 4 GB; Connectivity: Printer: Gigabit Ethernet (1000Base-T); Hi-Speed USB 3.0 certified; EIO Jetdirect accessory slot; Scanner: Gigabit Ethernet (1000Base-T); Hi-Speed USB 3.0 certified |
| Short product name |
SD Pro |
| Bit depth |
48-bit/16-bit |
| Product classification flag |
Standard HP Product |
| Media thickness maximum (metric) |
Up to 0.8 mm |
| Media types |
Printer: Bond and coated paper, technical paper, film, photographic paper, backlit, self-adhesive; Scanner: Non-abrasive paper, vellum, Mylar, sepia, blueprints, plastic, film, plastic laminate, foam board, cardboard, newspaper, tracing paper (no plywood, stone plates, metal plates or abrasive, dirty, rough, sharp edged, metal clamped, or burned surfaces or transparencies) |
| Master publishing date |
9/15/2016 |
| Tangible flag |
Y |
| Ideal for |
Quickly reproducing everyday documents in full detail, while taking advantage of multifunction capabilities with bundled HP Designjet printer. |
| Material Type for item |
FERT |
