SKU: 1PV64A
HP LaserJet Enterprise MFP M528dn
- Print technology
- Laser
- Display
- (20.3 cm), touchscreen (1024x768), LCD (color graphics), smooth gesture, enabled touchscreen
- Memory
- 1.25 GB (printer); 512 MB (Scanner)
Contact us for pricing
Key features
- Automatic document feeder
- Front USB flash drive port
- Flow
- Two-sided printing
- Low energy consumption
- World’s most secure printing
- Robust mobility
- Enhanced user interface
- Enterprise manageability
- Enhanced workflows
- Compact – small footprint
- More competitive cartridge offerings
Technical specifications
Product
| UPC number | (201) 192545079464; (696) 192545079440; (697) 196786252822; (AAZ) 192545079471; (AB0) 192545079310; (AB2) 192545079327; (ABJ) 192545079334; (ABT) 192545079372; (ABY) 192545079389; (AC8) 192545079457; (ACJ) 192545079341; (ACQ) 192545079396; (AKV) 192545696173; (B13) 192545079419; (B19) 192545079426; (BAZ) 192545079433; (BBU) 192545079358; (BGJ) 192545079488; (BGM) 192545079365 |
|---|---|
| Product type | Laser printers |
| Subcategory | Single and multifunction printers |
Memory
| Maximum Memory | 3.75 GB MAX memory, when Accessory DIMM is installed |
|---|---|
| Memory Slots | 1 slot, 144-pin, SODIMM |
| Memory upgrade | Expandable to 3.75 GB through one 144-Pin SODIMM HP accessory |
| Memory | 1.25 GB (printer); 512 MB (Scanner) |
Storage
| Storage temperature range | -20 to 40°C |
|---|
Display
| Display | (20.3 cm), touchscreen (1024x768), LCD (color graphics), smooth gesture, enabled touchscreen |
|---|---|
| Display area (metric) | 162 x 121.5 mm |
Wireless
| Wireless capability | Optional, enabled with purchase of a wireless hardware accessory. Single band Wireless Station and Wi-Fi Direct functionality available with HP Jetdirect 3000w NFC/Wireless Accessory J8030A, Dual band Wireless Station and Wi-Fi Direct functionality available with HP Jetdirect 3100w BLE/NFC/Wireless Accessory 3JN69A, Dual band Wireless Station functionality available with HP Jetdirect 2900nw Print Server J8031A |
|---|
Battery and power
| Power supply type | Built-in 115V or 220V Power Supply |
|---|
Software
| Compatible Operating Systems | Windows 11; Windows 10; Windows 8; Windows 8.1; Windows 7; Windows Client OS; Android; iOS; Mobile OS; macOS 10.12 Sierra; macOS 10.13 High Sierra; macOS 10.14 Mojave |
|---|---|
| Copier smart software features | Auto scale; Reduce/enlarge from scanner glass (25 to 400 percent); Collate; Auto color detection; Two-sided copying; Image adjustments (darkness, background cleanup, sharpness); Job build |
| Printer smart software features | Print preview, duplex printing, print multiple pages per sheet (2, 4, 6, 9, 16), collation, watermarks, store print jobs, easy-access USB |
| Print Technology | Laser |
|---|---|
| Mobile printing capability | HP ePrint; Apple AirPrint™; Mopria™ Certified; Google Cloud Print™ |
| Acoustic power emissions (active, printing) | 6.8 B(A) |
| Acoustic pressure emissions bystander (active, printing) | 54 dB(A) |
Copy and scan
| Scanner advanced features | Optimize text/picture; Image adjustments; Job build; Output quality setting; Selectable scan resolution 75 to 600 dpi; Auto detect color; Edge Erase; Job notification; Blank page suppression; HP Quick Sets |
|---|---|
| Copy reduce / enlarge settings | 25 to 400% |
| Copier scaling (ADF) | 25 to 200% |
| Copy resolution (black text) | Up to 600 x 600 dpi |
| Copy speed black duplex (A4) | Up to 34 cpm |
| Copy speed black duplex (Letter) | Up to 36 cpm |
| Copy speed (black, normal quality, A4) | Up to 43 cpm (default) ; Up to 50 cpm (HP High Speed) |
| Copy speed black (normal, letter) | Up to 45 cpm (default) ; Up to 52 cpm (HP High Speed) |
| First copy out black (A4) | As fast as 6.5 sec |
| First copy out black (A4, sleep) | As fast as 13 sec |
| Acoustic power emissions (active scan) | 6.7 B(A) |
| Acoustic pressure emissions bystander (active scan) | 52 dB(A) |
| Copyright notice | © Copyright 2019 HP Development Company, L.P. The information contained herein is subject to change without notice. The only warranties for HP products and services are set forth in the express warranty statements accompanying such products and services. Nothing herein should be construed as constituting an additional warranty. HP shall not be liable for technical or editorial errors or omissions contained herein. |
Paper handling
| Paper size | Letter; A4; Legal; B5 |
|---|
Physical
| Maximum dimensions (W x D x H) | 507 x 631 x 497 mm |
|---|---|
| Dimensions (W x D x H) | 482 x 496 x 497 mm |
Package
| Package dimensions (W x D x H) | 735 x 592 x 613 mm |
|---|---|
| Pallet dimensions (W x D x H) | 1200 x 800 x 1973 mm |
Sustainability
| Ecolabels | CECP; Blue Angel; EPEAT® Silver registered configurations available; ENERGY STAR® certified |
|---|---|
| Energy star certified | Yes |
| Sustainability specifications | Mercury free |
| Energy Usage CO2e (kg) | 45 |
| End of Life CO2e (kg) | 27 |
| Production CO2e (kg) | 215 |
| Total CO2e (kg) | 301 |
| Transportation CO2e (kg) | 14 |
Warranty and service
| Manufacturer Warranty | One-year, next-business day, onsite warranty. Warranty and support options vary by product, country and local legal requirements. Contact your Contractual Vendor or go to hp.com/support to learn about HP award winning service and support options in your region. (wty code 4G; wty ID A001) |
|---|---|
| Network protocols, supported | Via built-in networking solution: TCP/IP; IPv4; IPv6; Print: TCP-IP port 9100 Direct Mode; LPD (raw queue support only); Web Services Printing; IPP 2.0; Apple AirPrint™; HP ePrint; FTP Print; Google Cloud Print; Discovery: SLP; Bonjour; Web Services Discovery; IP Config: IPv4 (BootP; DHCP; AutoIP; Manual; TFTP Config; ARP-Ping); IPv6 (Stateless Link-Local and via Router; Stateful via DHCPv6); Management: SNMPv2/v3; HTTP/HTTPs; Telnet; TFTP Config; Syslog; Security: SNMPv3; SSL Cert Management; IPSec/Firewall; ACL; 802.1x |
| File Format Supported | JPG; MTIFF; PDF; PDF/A; TIFF; XPS |
Other
| Connection type | Wireless |
|---|---|
| Minimum System Requirements | 2 GB available hard disk space, Internet connection, USB port, Internet browser. For additional OS hardware requirements see microsoft.com |
| What's in the box | HP LaserJet Enterprise M528dn MFP; HP Original LaserJet Introductory Toner Cartridge (~7,500 pages); Regulatory flyer (CD replacement); Chile Regulatory flyer (AC8); Unpack flyer; Installation Guide; Power cord; Warranty Cards; Support flyers/phone number list Japan jtr errata (ABJ) |
| Energy savings feature technology | HP Auto-On/Auto-Off Technology; Instant-on Technology; Instant-on Copy |
| Power consumption | 629 watts (Printing), 28.8 watts (Ready), 5.3 watts (Sleep), 0.74 watts (Auto-Off/Auto-On), LAN connection: 0.06 watts (Auto-Off), 0.06 watts (Off) |
| Power | Input voltage: 100V to 127V nominal (+/-10%), 50 - 60 Hz nominal (+/- 3 Hz), 7.5 A; Input voltage: 220V to 240V nominal (+/-10%), 50 - 60 Hz nominal (+/- 3 Hz), 4 A |
| Cable included | No, please purchase USB cable separately |
| Registration required | No |
| Print Cartridges/Bottle, Number | 1 (black) |
| Replacement cartridges | HP 89A Black Original LaserJet Toner Cartridge (~5,000 pages) CF289A; HP89X High Yield Black Original LaserJet Toner Cartridge (~10,000 pages) CF289X; HP89Y Extra High Yield Black Original LaserJet Toner Cartridge (~20,000 pages) CF289Y |
| Supplies feature | HP JetIntelligence Cartridge |
| Brand | HP |
| Sub brand | LaserJet Enterprise |
| Blue Angel compliant | Yes, Blue Angel DE-UZ 219—only ensured when using Original HP supplies |
| Certifications and compliances | CSA (Canada), ACA (Australia), TUV and GS Mark (Germany), BSMI (Taiwan), CCC (China), MIC (South Korea), NOM (Mexico), Nemko, Fimko, Demko, Semko (Nordic), Eastern European approvals, CE Marking, FCC approval, Energy Star, TCO '99, Windows certified (Microsoft Windows 2000 and Microsoft Windows XP), UL listed |
| Electromagnetic compatibility | CISPR 22:2008 (International) - Class A, CISPR32:2012 (International) - Class A, EN 55032: 2012 (EU) - Class A, EN 61000-3-2: 2014, EN 61000-3-3: 2013, EN 55024: 2010, EMC Directive 2014/30/EU, FCC CFR 47 Part 15 Class A/ICES-003, Issue 6 Class A. Other EMC approvals as required by individual countries. |
| FCC Class A emissions | FCC Class A emissions - for use in commercial environments, not residential environments |
| Safety | IEC 60950-1:2005 +A1:2009 +A2:2013 (International); EN60950-1:2006 +A11:2009 +A1:2010 +A12:2011 +A2:2013 (EU); EN 60825-1:2014/IEC 60825-1:2014 (Class 1 Laser Product); EN 62479:2010/IEC 62479:2010; Low Voltage Directive 2014/35/EU with CE Mark (Europe); IEC 62471:2006/EN 62471:2008 (LED lighting); GS Certificate (Germany, Europe); UL/cUL Listed and UC CoC (US/Canada); CAN/CSA C22.2 No. 60950-1-07 2nd Ed. 2011-12; Compliance with Laser safety standards 21 CFR 1040.10 and 1040.11 except for deviations pursuant to Laser notice No. 50, Dated June 24, 2007; Other safety approvals as required by individual countries. |
| Accessories | HP LaserJet 550 Sheet Paper Tray F2A72A, HP LaserJet Printer Cabinet F2A73A, HP USB Port 100pc M507/M528 Accessory 1PV95A, HP Secure Hard Disk Drive with FIPS Validation (TAA Compliant) 5EL03A, HP Internal USB Ports B5L28A, HP Foreign Interface Harness B5L31A, HP Secure High Performance Hard Disk Drive B5L29A, HP MFP Analog 700 Fax Accessory 2EH31A, HP Jetdirect 3000w NFC/Wireless Accessory J8030A, HP Jetdirect 2900nw Print Server J8031A, HP JetDirect 3100w BLE/NFC/Wireless Accessory 3JN69A HP DDR3 x32 144-Pin 800 MHz SODIMM E5K48A, HP DDR3x32 144-Pin 800 MHz SODIMM Accessory E5K49A, HP Removable Hard Drive Enclosure 2NR12A, Accessibility Assistant 2MU47A, HP Accessibility Kit 2TD64A, HP USB Universal Card Reader X3D03A, HP HIP2 Keystroke Reader Y7C05A, HP Logic Card Reader 4QL32A |
| Orderable supplies | HP 200 ADF Roller Replacement Kit W5U23A |
| Connectivity | USB; Ethernet networking; Wireless optional (with accessory) |
| Number of users | 5-15 Users |
| Connectivity, optional | HP Jetdirect 2900nw Print Server J8031A; HP Jetdirect 3000w NFC/Wireless Accessory J8030A; HP Jetdirect 3100w BLE/NFC/Wireless Accessory 3JN69A |
| Connectivity, standard | 1 Hi-Speed Device USB 2.0; 2 Hi-Speed USB 2.0 Host; 1 Gigabit Ethernet; 1 Hardware Integration Pocket |
| Network capabilities | Yes, via HP Jetdirect Ethernet embedded print server (standard) which supports: 10Base-T, 100Base-Tx, 1000Base-T; 802.3az (EEE) support on Fast Ethernet and Gig Links; IPsec (standard); 802.11a/b/g/n wireless networking (optional); second Ethernet port (optional); Microsoft Universal Print (MUP) support |
| Plug and play | HP Smart Install |
| Copier settings | Two-sided copying; scalability; image adjustments (darkness, contrast, background cleanup, sharpness); N-up; N or Z-ordering; content orientation; collation; booklet; job build; edge-to-edge job storage; ID Copy; Book Copy; A-to-B Copy (different media sizes) |
| Copies, maximum | Up to 9999 copies |
| Digital sending optional features | Authentication; Digital fax (send to LAN, Internet); HP Digital Sending Software; Local Address Book; OCR; Send-to-folder; Send-to-printer; Send-to-workflow |
| Digital sending standard features | Scan to E-mail; Scan-to-Sharepoint; Save-to-Network Folder; Save-to-USB drive; Send to FTP; Send to Internet Fax; Local Address Book; SMTP over SSL; Blank Page Removal; Edge Erase; Auto Color Sense; Auto Crop To Content; Compact PDF |
| Maximum metric depth | 631 |
| Maximum metric height | 497 |
| Maximum metric width | 507 |
| Metric depth | 496 |
| Metric width | 482 |
| Business filter | cMPS |
| Component type | Printer |
| Printer black pages (MPV black) | 2400 |
| Acoustic power emissions (ready) | 4.0 B(A) |
| Acoustic pressure emissions bystander (ready) | 26 dB(A) |
| Operating humidity range | 10 to 80% RH |
| Recommended operating humidity range | 30 to 70% RH |
| Operating temperature range | 10 to 32.5°C |
| Recommended operating temperature range | 15 to 27°C |
| Faxing | Optional |
| Functions | Multifunction / All-in-One |
| Form factor | Multifunction |
| Country of origin | Made in Brazil; Made in China; Made in Czech Republic; Made in Mexico |
| Datasheet publication number | 4AA7-4188EEP |
| Web address for additional information | Solutions: http://www.hp.com/go/gsc; Fonts and IPDS Emulation: http://www.hp.com/go/laserjetfonts; HP Web Jetadmin: http://www.hp.com/go/wja; HP Universal Print Driver: http://www.hp.com/go/upd; HP Imaging & Printing Security Center: http://www.hp.com/go/ipsc; On Demand Cloud Solutions: http://www.hpjetadvantage.com/ondemand Product Support: http://www.hp.com/support/ljM527MFP |
| Differentiator (features) | Redefine long-term expectations |
| Why to buy | Choose an HP LaserJet Enterprise MFP designed to handle business solutions securely and efficiently, and helps conserve energy with HP JetIntelligence toner. Keep up with the demands of growing business with a printer you can rely on. |
| Headline | HP printers have the industry’s strongest security[1] because they’re always on guard, continually detecting and stopping threats while adapting to new ones. And only HP printers automatically self-heal from attacks, so IT doesn’t need to intervene. |
| Key selling point | Firmware is automatically checked during startup to determine if it’s authentic code—digitally signed by HP. |
| Image legal disclaimer | Product image may differ from actual product |
| Legal disclaimer | ENERGY STAR and the ENERGY STAR logo are registered U.S. marks. Microsoft and Windows are registered trademarks of Microsoft Corporation. AirPrint and the AirPrint logo are trademarks of Apple Inc., registered in the U.S. and other countries. Linux is a U.S. registered trademark of Linus Torvalds. UNIX is a registered trademark of The Open Group. |
| Monthly printed pages | 150000 |
| Segment | Business |
Notes and footnotes
- [18] Requires HP FutureSmart 5.8.1.1 or later.
- A product carbon footprint is defined as the total amount of greenhouse gases emitted directly and indirectly by a product over its lifetime. Greenhouse gas emissions are reported as global warming potential for 100-year time horizon (GWP-100) in units of CO2 equivalence. Calculations are done in accordance with ISO 14040 & ISO 14044. Individual values may not sum to total due to rounding.
- [1] Based on HP review of 2018 published security features of competitive in-class printers. Only HP offers a combination of security features that can monitor to detect and automatically stop an attack then self-validate software integrity in a reboot. For a list of printers, visit hp.com/go/PrintersThatProtect. For more information: http://www.hp.com/go/printersecurityclaims
- [2] High Yield Black Original LaserJet Toner Cartridges not included; please purchase separately
- [3] HP Auto-On/Auto-Off Technology capabilities are subject to printer and settings.
- [1] In box cartridge yields 7,500 black pages based on ISO/IWC 19752 and continuous printing. Actual pages may vary considerably based on images printed and other factors. For more information, visit: http://www.hp.com/go/learnaboutsupplies.
- [4] HP Web Jetadmin is available for download at no additional charge at http://www.hp.com/go/webjetadmin
- [5] HP JetAdvantage Security Manager must be purchased separately. To learn more, please visit http://www.hp.com/go/securitymanager
- [2] With print cartridges
- [6] Scan speeds measured from ADF. Actual processing speeds may vary depending on scan resolution, network conditions, computer performance, and application software.
- [3] Power requirements are based on the country/region where the printer is sold. Do not convert operating voltages. This will damage the printer and void the product warranty. Power consumption values typically based on measurement of 115V device.
- [7] HP Secure Print is optional and requires a license.
- [4] Declared yield value in accordance with ISO/IEC 19752. Actual yields vary considerably based on images printed and other factors. For more information, visit: http://www.hp.com/go/learnaboutsupplies
- [8] HP calculations based on Energy Star normalized TEC data comparing the HP LaserJet 500 series monochrome printers introduced in spring 2019 HP 89A/X/Y compared to HP 87A/X.
- [5] HP recommends that the number of pages per month of imaged output be within the stated range for optimum device performance, based on factors including supplies replacement intervals and device life over an extended warranty period.
- [9] An FCC Class A emissions compliant device meets the less stringent (higher) levels of emissions allowed by the FCC for a product operation in a commercial environment. An FCC class A device cannot be marketed for use in a residential environment and an FCC class A device should not be purchased for use in a residential environment due to the increased risk of interference to radio communications.
- [6] HP SureSupply alerts you when your print cartridge is running low and helps you purchase online or locally through HP or a participating retailer. Only available with Original HP supplies; Internet access required. To learn more, visit http://www.hp.com/go/SureSupply.
- [7] Power requirements are based on the country/region where the printer is sold. Do not convert operating voltages. This will damage the printer and void the product warranty. Energy Star value typically based on measurement of 115V device.
- [8] Best TEC is not applicable to ES 2.0 TEC. This measurement was made with the printer configuration optimized for energy efficiency. Minimum sleep delay was used, Wi-Fi Direct was disabled and Active I/O - Energy Efficient Ethernet - was used.
- [9] EPEAT® registered where applicable. EPEAT registration varies by country. See http://www.epeat.net for registration status by country.
- [10] Scan speeds measured from ADF. Actual processing speeds may vary depending on scan resolution, network conditions, computer performance, and application software.
- [11] EPEAT® registered where applicable. EPEAT registration varies by country. See http://www.epeat.net for registration status by country.
- [12] Measured using ISO 24734 Feature Test,A5 Landscape Feed. Speed may vary based on content, PC, media orientation, and media type.
- [13] Measured using ISO/IEC 24734 Office Suite and Feature Tests, excludes first set of test documents. For more information see http://www.hp.com/go/printerclaims. Exact speed varies depending on the system configuration, software application, driver, document complexity, media size, media orientation and media type. HP High Speed may require FW upgrade to enable.
- [14] Measured using ISO/IEC 24734 Office Suite and Feature Tests, excludes first set of test documents. For more information see http://www.hp.com/go/printerclaims. Exact speed varies depending on the system configuration, software application, driver, document complexity, media size, media orientation and media type. HP High Speed may require FW upgrade to enable.
- [15] First Copy Out from Ready and Simplex Copy Speed measured using ISO/IEC 29183, Duplex Copy Speed measured using ISO/IEC 24735, excludes first set of test documents. For more information see http://www.hp.com/go/printerclaims. Exact speed varies depending on the system configuration, software application, document complexity, media size, media orientation and media type. HP High Speed may require FW upgrade to enable.
- [16] Configuration tested: base model, simplex printing, A4 paper at an average of 43 ppm.
- [17] Configuration tested: base model, simplex printing, A4 paper at an average of 43 ppm.
- FCC Class A emissions device for use in commercial environments, not residential environments[9]
- [17] Maximum physical memory present is reported. Actual usable amount by firmware might be less.
