| What's in the box |
Printer: HP DesignJet Z6dr 44-in PostScript Printer with V-Trimmer, printheads, introductory ink cartridges, printer stand and media bin, spindle, 3-in core adapter, quick reference guide, setup poster, power cord; Scanner: HP HD Pro 2 42-in Scanner, stand, touchscreen (panel PC), quick reference guide, media guides, setup poster, maintenance sheet, copy/scan software, documentation software, Ethernet cable, USB cable, power cords |
| Power consumption |
Printer: |
| Power |
Printer: Input voltage (auto ranging) 100-240 V (±10%), 50/60 Hz (±3 Hz), 2 A max; Scanner: Input voltage (auto ranging): 100-240 V (±10%), 50/60 Hz, 5 A max |
| Registration required |
No |
| Cartridge volume |
300 ml |
| Ink drop |
7/3 pl dual-drop weight (M, C, PK); 6 pl single-drop weight (Y, CR, MK) |
| Ink types |
Pigment-based |
| Number of cartridges |
6 |
| Print Cartridges/Bottle, Number |
6 (cyan, magenta, yellow, matte black, photo black, chromatic red) |
| Print head nozzles |
2112 per color; 12,672 in total |
| Print heads |
3 universal printheads (valid for all colors) |
| Primary applications |
Advertising posters, roll-ups, and banners; Design and illustrations; Maps; Indoor signage; Décor |
| Sub brand |
DesignJet |
| Electromagnetic compatibility |
Printer: Compliant with Class B requirements, including: USA (FCC rules), Canada (ICES), EU (EMC Directive), Australia (ACMA), New Zealand (RSM), China (CCC), Japan (VCCI), Korea (KCC), South Africa (SABS); Scanner: Compliance for Class A ITE products: EU (EMC Directive), USA (FCC Rules), Canada (ICES), Australia (ACMA), New Zealand (RSM), China (CCC), Japan (VCCI), Korea (MSIP), Taiwan (BSMI), Russia (EAC) |
| Safety |
Printer: USA and Canada (CSA certified); EU (LVD and EN 60950-1 compliant); Russia, Belarus, Khazakstan (EAC); Singapore (PSB); China (CCC); Argentina (IRAM); India (BIS); Scanner: USA and Canada (UL certified); EU (LVD and EN 60950-1 compliant); Russia (EAC); Singapore (PSB); China (CCC); Argentina (IRAM); Mexico (NYCE); Korea (KC) |
| Accessories |
CN538A HP DesignJet 3-in Core Adapter;N7P47A HP USB 3.0 to Gigabit LAN Adapter;P7V13A HP Pro Scanner Output Delivery Tray;Q6709A HP DesignJet 44-in Spindle;1QF38A HP DesignJet 44-in Take-up Reel |
| Connectivity, standard |
Printer: Gigabit Ethernet (1000Base-T), Hi-Speed USB 2.0 certified interface for direct printing from USB flash drive; Scanner: Gigabit Ethernet (1000Base-T), USB 3.1 gen 1 (3+1) and USB 2.0 (1) rear |
| Interface |
15.6" (396-mm) large touchscreen to preview and enhance images |
| Network ready |
Standard |
| Copier settings |
Type of original, image crop and align preview, lightness, saturation and RGB controls, white point and black point adjust, sharpen/blur, mirror copy, enlarge/reduce, paneling, tiling, nesting, accounting, batch, multipage PDF generation, invert, collate copy with reprint |
| Acoustic pressure emissions |
Printer: 45 dB(A) (operating), 33 dB(A) (idle), |
| Operating humidity range |
20 to 80% RH |
| Operating temperature range |
41 to 95ºF |
| Country of origin |
China |
| Why to buy |
Work productively with the HP DesignJet HD Pro 2 44-in MFP. Combine CCD scanning technology with an enhanced feature set that drives quality results and greater efficiency for streamlined workflows. |
| Headline |
Reproduce colors with excellent accuracy with CCD technology. The advanced five-camera system captures detail in high precision. You can even scan old and damaged documents—up 42-in (1067-mm) wide—and achieve great results. |
| Key selling point |
Reliable color—HP Professional PANTONE® color emulation, embedded Adobe® PostScript®, Adobe® PDF Print Engine. |
| Image legal disclaimer |
Product image may differ from actual product |
| Product logos |
Adobe PostScript 3; Adobe PDF Print Engine 4; CE Marking; EPEAT; Gold IPv6 Ready; Intel Inside Core i5; Mac; PANTONE Digital Color; Windows 10 Compatible |
| Taxonomy |
Large Format Printers/ Plotters |
| Segment |
Business |
| Non-printable area (cut-sheet) |
0.2 x 0.67 x 0.2 x 0.2 in |
| Non-printable area (roll media) |
Borderless on all media with V-Trimmer[2] |
| Functions |
Print, copy, scan |
| Model size |
Printer: 1118 mm; Scanner: 1067 mm |
| Printer drivers included |
Printer: Raster and PostScript drivers for Windows and macOS; PDF driver for Windows 8 and above; Scanner: Windows drivers for compatible HP PageWide XL and HP DesignJet Printers |
| Print languages |
Adobe PostScript 3, Adobe PDF 1.7, TIFF, JPEG, CALS G4, HP-GL/2, HP-RTL |
| Maximum roll diameter |
5.3 in |
| Media thickness |
Up to 31.5 mil |
| Media width, maximum |
1118 mm |
| Printer Applications |
Architecture; Retail signage; Maps; Photographs; Fine art reproduction |
| Recommended media |
HP Universal Instant-dry Satin Photo Paper (FSC® certified)[5] (Recyclable)[6]; HP Artist Matte Canvas; HP Heavyweight Coated Paper (FSC® certified)[5] (Recyclable)[6]; HP Everyday Matte Polypropylene (Recyclable)[6]; HP Premium Matte Photo Paper (FSC® certified)[5] (Recyclable)[6] |
| Roll maximum input |
2 |
| Roll size |
Up to 44 in |
| Product Disclaimer |
Certain HP printers are intended to work only with cartridges that have a new or reused HP chip or electronic circuitry. These printers use dynamic security measures to block cartridges using a non-HP chip or electronic circuitry. Periodic firmware updates will maintain the effectiveness of these measures and block cartridges that previously worked. Reused HP chips and electronic circuitry enable the use of reused, remanufactured, and refilled cartridges. |
| Dynamic security |
Dynamic security enabled printer |
| Overview |
Quickly print and scan maps, drawings, POP graphics/displays, posters, photos, and more with the HP DesignJet HD Pro 2 44-in MFP. See high-quality results delivered efficiently and securely. |
| Company |
HPI |
| Code name |
Jaguar 6 bundle |
| Product long name |
HP DesignJet HD Pro 2 44-in MFP |
| Product classification flag |
Standard HP Product |
| Media thickness maximum (metric) |
Up to 0.8 mm |
| Media types |
Printer: Photographic, fine art printing material, self-adhesive, banner and sign, bond and coated, backlit; Scanner: Non-abrasive paper, vellum, Mylar, sepia, blueprints, plastic, film, plastic laminate, foam board, cardboard, newspaper, tracing paper. Varying condition documents: old, delicate, folded, creased, crumpled, damaged originals (no plywood, stone plates, metal plates or abrasive, dirty, rough, sharp edged, metal clamped, or burned surfaces or transparencies) |
| Tangible flag |
Y |
| Material Type for item |
FERT |
