Back to DesignJet / Large Format
SKU: 2Y9H4A
HP DesignJet Smart Tank T858 36-in Printer
- Print technology
- Ink
- Memory
- 1 GB
Contact us for pricing
Key features
- Touchscreen
- Automatic document feeder
Technical specifications
Product
| UPC number | (ABG) 197192532843; (AC4) 198415341594; (ACJ) 197192532850; (AKV) 198828596994; (B19) 197192532867; (B1K) 197192532881; (BCD) 197192532898 |
|---|---|
| Product type | Office Printers for CAD and GIS |
| Subcategory | Large format |
| UNSPSC code | 43212104 |
Memory
| Memory | 1 GB |
|---|
Storage
| Storage temperature range | -13 to 131°F |
|---|---|
| Internal Storage | None |
Display
| Product display name | HP DesignJet Smart Tank T858 36-in Printer with Refillable Ink Tank, Spill-free Ink Bottles, Integrated A3 Input Tray |
|---|
Software
| Software included | HP Click App, HP Click Driver for Windows 11, HP app for Windows, macOS, Android, and iOS |
|---|
| Print technology | HP Thermal Inkjet |
|---|---|
| Acoustic power emissions (active, printing) | 5.8 B(A) (operating), |
| Print quality color (best) | Up to 2400 x 1200 optimized dpi |
| Print speed | 25 sec/page on A1, 90 A1 prints per hour[1] |
| Printing path | Wi-Fi Direct, remote printing, HP Click App, HP Click Driver for Windows 11, Apple AirPrint and HP app for Android and iOS devices, Windows and macOS printer drivers, printing support for Chrome OS |
Copy and scan
| Copyright notice | © Copyright 2026 HP Development Company, L.P. The information contained herein is subject to change without notice. The only warranties for HP products and services are set forth in the express warranty statements accompanying such products and services. Nothing herein should be construed as constituting an additional warranty. HP shall not be liable for technical or editorial errors or omissions contained herein. |
|---|
Paper handling
| Media size maximum (mm) | 914 |
|---|---|
| Media size maximum (in) | 36 |
| Media sizes standard (metric rolls) | 369 to 914 mm |
| Media sizes standard (sheets, rolls) | 14.5 to 36 in |
| Media sizes, custom | Input tray: 210 x 279 to 305 x 457 mm; Manual feed: 210 x 279 to 914 x 1676 mm |
| Media sizes supported | Input tray: A4, A3; Manual feed: A4, A3, A2, A1, A0 |
Physical
| Print Cartridge/Bottle, Color(s) | Cyan, magenta, yellow, matte black |
|---|---|
| Dimensions (W x D x H) | 58.1 x 27.6 x 38.1 in |
| Color or black | Color |
| Roll maximum weight | 13.6 lb |
| Finished output handling | Sheet feed, roll feed, input tray (50 sheet capacity), media bin, automatic horizontal cutter |
| Media weight, recommended | 60 to 280 g/m² (roll/manual feed); 60 to 220 g/m² (input tray) |
| Weight | 112.4 lb |
Package
| Package dimensions (W x D x H) | 63.5 x 22.5 x 25.5 in |
|---|---|
| Package weight | 167.5 lb |
Sustainability
| Energy star certified | Yes |
|---|---|
| Environmental certification | ENERGY STAR, EPEAT, UL ECOLOGO® certified inks, CE marking (including WEEE, RoHS, REACH, ErP). In compliance with applicable WW RoHS materials restriction requirements. |
| Energy Usage CO2e (kg) | 281 |
| End of Life CO2e (kg) | 21 |
| Post consumer recycled plastic in hardware by weight of plastic | 43% |
| Production CO2e (kg) | 360 |
| Total CO2e (kg) | 694 |
| Transportation CO2e (kg) | 32 |
Warranty and service
| Manufacturer Warranty | One-year limited hardware warranty. Warranty and support options vary by product, country and local legal requirements. |
|---|---|
| Supported Primary Applications | Line drawings; Maps; Posters; Presentations; Renderings |
| Playbook BTF e-tail Supporting (medium) | Use up to 85% less ink for routine maintenance vs. competitor and get up to 192 extra A1 pages per month.[4] |
Other
| What's in the box | HP DesignJet Smart Tank T858 Printer, printhead, ink bottles, printer stand, spindle, guide, poster, warranty flyer, power cord |
|---|---|
| Power consumption | 35 W (printing), |
| Power | Input voltage (auto ranging): 100-240 V (±10%), 50/60 Hz (±3 Hz), 1.2 A max |
| Registration required | No |
| Ink drop | 6 pl (C, M, Y); 12.6 pl (mK) |
| Ink types | Dye-based (C, M, Y); pigment-based (mK) |
| Print Cartridges/Bottle, Number | 4 (C, M, Y, mK) bottles |
| Print cartridge/bottle volume | 500 ml per bottle |
| Print head nozzles | 1376 per color; 5504 in total |
| Print heads | 1 (C, M, Y, mK) |
| Primary applications | Office documents and presentations; Engineering and construction documents; Advertising posters, roll-ups, and banners; Design and illustrations; Maps |
| Sub brand | DesignJet |
| Electromagnetic compatibility | Compliant with Class B requirements, including: USA (FCC rules), Canada (ICES), EU (RED Directive), Australia (ACMA), New Zealand (RSM), China (CCC), Japan (VCCI); Korea (KCC) |
| Safety | USA and Canada (CSA certified); EU (RED Directive, EN 62368-1 compliant); Singapore (PSB); China (CCC); Mexico (NYCE); Argentina (IRAM); India (BIS) |
| Orderable supplies | HP Original Ink: HP V87XL bottles (Black, Cyan, Magenta, Yellow), and HP 4287 printhead |
| Connectivity | Apple AirPrint™; Ethernet networking; Wireless (Wi-Fi®); Wireless direct printing |
| Connectivity, standard | Gigabit Ethernet (1000Base-T), Wi-Fi 802.11b/g/n |
| Network ready | Standard |
| Security features | HP Wolf Pro Security, HP Secure Boot, Allowlisting, Security event logging, Disable network ports and protocols, SNMPv3, 802.1x compatibility, TLS/SSL, HP Web JetAdmin, HP Security Manager, SIEM Integration |
| Acoustic pressure emissions | 42 dB(A) (operating), |
| Non-Operating Humidity Range | 0 to 95% RH |
| Operating altitude | Up to 9843 ft |
| Operating humidity range | 20 to 80% RH |
| Operating temperature range | 41 to 104°F |
| Functions | Print only |
| Country of origin | China |
| Why to buy | Speed and efficiency are essentials for today’s copy shops. And now you can easily meet high demand with a compact ink tank printer that delivers big results in both A1 and A3 sizes. It’s always ready and drives the efficiencies you’re looking for. |
| Headline | Accelerate turnarounds with a fast ink tank that easily accommodates A3 jobs with its integrated input tray—no manually changing from roll to sheets. Address peaks with speeds up to 90 A1/D plots per hour.[1] And print in fewer steps with HP Click. |
| Key selling point | Do it all—also print A3 jobs using the integrated input tray, without manually changing from roll to sheets. |
| Image legal disclaimer | Product image may differ from actual product |
| Product logos | AirPrint; CE marking; ENERGY STAR; EPEAT green; IPv6 Ready; Mac; Wi-Fi Certified; Windows 11 Compatible; HP Wolf Pro Security |
| Monthly printed pages | Often |
| Taxonomy | Large Format Printers/ Plotters |
| Segment | Business |
| Non-printable area (cut-sheet) | 0.2 x 0.2 x 0.2 x 0.2 in |
| Maximum optical density (black) | 24 L* min/1.4 D[3] |
| Line accuracy | ±0.1%[2] |
| Model size | 914 mm |
| Printer drivers included | Raster driver for macOS and Windows, HP Click Driver for Windows 11, HP-GL/2 driver for Windows |
| Print languages | TIFF, JPEG, URF, HP-GL/2, HP-RTL, CALS G4 |
| Theoretical minimum line width | 0.0008 in (via raster driver) |
| Media thickness | Up to 11.8 mil |
| Recommended media | HP Universal Bond Paper (FSC® certified)[4] (recyclable)[5];HP Coated Paper (FSC® certified)[4] (recyclable)[5];HP Heavyweight Coated Paper (FSC® certified)[4] (recyclable)[5] |
| Roll external diameter | 3.9 in |
| Roll maximum input | 1 |
| Product Disclaimer | Certain HP printers are intended to work only with cartridges that have a new or reused HP chip or electronic circuitry. These printers use dynamic security measures to block cartridges using a non-HP chip or electronic circuitry. Periodic firmware updates will maintain the effectiveness of these measures and block cartridges that previously worked. Reused HP chips and electronic circuitry enable the use of reused, remanufactured, and refilled cartridges. |
| Dynamic security | Dynamic security enabled printer |
| Overview | Get ahead with a fast ink tank that accommodates both A1 and A3 sizes easily. It’s simple to use and always ready—you can refill ink even while the printer is printing. Enjoy big results from an efficient and compact printer. |
| Company | HPI |
| Code name | Pixiu Basic |
| Product long name | HP DesignJet Smart Tank T858 36-in Printer |
| Short product name | T858 |
| Product classification flag | Standard HP Product |
| Media thickness maximum (metric) | Up to 0.3 mm |
| Media types | Bond and coated paper (bond, coated, heavyweight coated, plain, bright white, blueprint), technical paper (natural tracing), film (clear, matte), photographic paper (ID satin, ID gloss), self-adhesive (adhesive matte/gloss, adhesive polypropylene gloss), Polypropylene (matte) |
| Technical features | Refillable ink tank;Ink bottles;Ink level alerts;1-click scan/copy;Auto-power on/off scheduler;2L start-up ink bottle;A3 input tray |
| Tangible flag | N |
| Ideal for | cost-conscious copy shops looking for an ink tank printer that is fast and efficient, delivers high HP DesignJet quality, and is always ready. |
| Playbook e-tail Gallery header | Print A3 jobs, too, with the integrated input tray |
| Playbook BTF e-tail Header | Efficient ink routine maintenance |
| Material Type for item | FERT |
Notes and footnotes
- A product carbon footprint is defined as the total amount of greenhouse gases emitted directly and indirectly by a product over its lifetime. Greenhouse gas emissions are reported as global warming potential for 100-year time horizon (GWP-100) in units of CO2 equivalence. Calculations are done in accordance with ISO 14040 & ISO 14044. Individual values may not sum to total due to rounding.
- [1]Printing on plain paper in Fast Economode.
- [2]HP One-click printing with HP Click software. HP Click software is only compatible with Original HP ink supplies. Applicable to PDF, JPEG, TIFF, DWF, and HP-GL/2 files.
- [3]Spill-free results when used in accordance with set-up instructions.
- [1] Mechanical printing time. Printed in Fast mode with Economode on, using HP Bright White Inkjet Paper (bond) and Original HP inks.
- [4]HP DesignJet T858 effectively reduces wasted ink during maintenance routines compared to other 36-in 4-color ink tanks, based on testing performed by Sogeti in February 2023, evaluating the amount of ink wasted per each normal printhead cleaning.
- [2] ±0.1% of the specified vector length or ±0.2 mm (whichever greater) at 23ºC (73ºF), 50-60% relative humidity, on A0/E printing material in Best or Normal mode with HP Heavyweight Coated roll feed and Original HP inks.
- [3] With HP Universal Instant Dry Photo Gloss media with Original HP inks.
- [4] BMG trademark license code FSC®-C115319, see http://www.fsc.org . HP trademark license code FSC®-C017543, see http://www.fsc.org
- [5] Can be recycled through commonly available recycling programs.
