| What's in the box |
HP HD Pro 2 42-in Scanner, stand, touchscreen (panel PC), quick reference guide, media guides, setup poster, maintenance sheet, copy/scan software, documentation software, Ethernet cable, USB cable, power cords |
| Power consumption |
130 W (scanning), 39 W (ready), < 1 W (sleep) |
| Power |
Input voltage (auto ranging): 100-240 V (±10%), 50/60 Hz, 5 A max |
| Registration required |
No |
| Electromagnetic compatibility |
Compliance for Class A ITE products: EU (EMC Directive), USA (FCC Rules), Canada (ICES), Australia (ACMA), New Zealand (RSM), China (CCC), Japan (VCCI), Korea (MSIP), Taiwan (BSMI), Russia (EAC) |
| Safety |
USA and Canada (UL certified), EU (LVD and EN 60950-1 compliant), Russia (EAC), Singapore (PSB), China (CCC), Argentina (IRAM), Mexico (NYCE), Korea (KC) |
| Accessories |
P7V13A HP Pro Scanner Output Delivery Tray |
| Compatibility |
HP DesignJet T920 Printer series; HP DesignJet T930 Printer series; HP DesignJet T940 Printer; HP DesignJet T790 Printer series; HP DesignJet T795 Printer; HP DesignJet T1300 PostScript® Printer; HP DesignJet T1500 Printer series; HP DesignJet T1530 Printer series; HP DesignJet T1600 Printer; HP DesignJet T1700 Printer series; HP DesignJet T2500 Multifunction Printer series; HP DesignJet T2530 Multifunction Printer series; HP DesignJet T2600 Multifunction Printer series; HP DesignJet T3500 Production Multifunction Printer; HP DesignJet XL 3600 Multifunction Printer; HP PageWide XL 39x0, 4x00, 5x00, 6x00, 8x00 Printers; HP DesignJet Z6/Z9+ PostScript® Printer series; HP DesignJet Z6/Z9+ Pro Printer series; HP DesignJet Z5200 Photo Printer; HP DesignJet Z5400 PostScript® Printer; HP DesignJet Z5600 PostScript® Printer; HP DesignJet Z6610 Production Printer; HP DesignJet Z6810 Production Printer series |
| Connectivity, standard |
Gigabit Ethernet (1000Base-T), USB 3.1 gen 1 (3+1) and USB 2.0 (1) rear |
| Interface |
15.6" (396-mm) large touchscreen to preview and enhance images |
| Network ready |
Standard |
| Copier settings |
Type of original, image crop and align preview, lightness, saturation and RGB controls, white point and black point adjust, sharpen/blur, mirror copy, enlarge/reduce, paneling, tiling, nesting, accounting, batch, multipage PDF generation, invert, collate copy with reprint |
| Acoustic pressure emissions |
48 dB(A) (operating), |
| Non-Operating Humidity Range |
0 to 95% RH |
| Operating humidity range |
20 to 80% RH |
| Operating temperature range |
41 to 95ºF |
| Country of origin |
Denmark(BCB, ) |
| Plus |
CCD scanning technology, scans/copies up to 42 inches (1067 mm), media support up to 15-mm thick |
| Why to buy |
This high-production HD scanner delivers speed and quality without compromise. Combine CCD scanning technology with an enhanced feature set that drives quality results and greater efficiency for streamlined workflows in busy production environments. |
| Headline |
Work effectively with a seamless, secure workflow. This scanner integrates perfectly with HP printers, simplifying maintenance of the complete solution. Avoid reprints with intuitive touchscreen. Secure your workflow with advanced security features. |
| Key selling point |
Save time operating and managing your scanner with an intuitive user interface that requires less clicks to final scan. |
| Image legal disclaimer |
Product image may differ from actual product |
| Product logos |
CE Marking; ENERGY STAR®; EPEAT; Intel Inside Core i5 |
| Taxonomy |
Scanners and Fax |
| Functions |
Copy, scan |
| Model size |
1067 mm |
| Printer drivers included |
Windows drivers for compatible HP PageWide XL and HP DesignJet Printers |
| Media width, maximum |
1118 mm |
| Overview |
Produce high-quality HD results with CCD scanning technology. Streamline workflows with incredible scan and processing speeds. Improve efficiency and productivity with an enhanced feature set. Enjoy easy integration with HP large-format printers. |
| Company |
HPI |
| Code name |
Dixie |
| Product long name |
HP HD Pro 2 42-in Scanner |
| Bit depth |
48-bit/16-bit |
| Product classification flag |
Standard HP Product |
| Media types |
Non-abrasive paper, vellum, Mylar, sepia, blueprints, plastic, film, plastic laminate, foam board, cardboard, newspaper, tracing paper. Varying condition documents: old, delicate, folded, creased, crumpled, damaged originals (no plywood, stone plates, metal plates or abrasive, dirty, rough, sharp edged, metal clamped, or burned surfaces or transparencies) |
| Tangible flag |
Y |
| Ideal for |
GIS professionals, repro houses, and CRDs in enterprises who value high-definition document scanning, copying, and image enhancement with precise color accuracy for artwork, maps, photos, and technical drawings in any condition. |
| Material Type for item |
FERT |
