| What's in the box |
HP SD Pro 2 44-in Scanner, stand, touchscreen (panel PC), quick reference guide, media guides, setup poster, maintenance sheet, copy/scan software, documentation software, Ethernet cable, USB cable, power cords |
| Power consumption |
47 W (scanning), 32 W (ready), 1.8 W (sleep) |
| Power |
Input voltage (auto ranging): 100-240 V (±10%), 50/60 Hz, 5 A max |
| Registration required |
No |
| Electromagnetic compatibility |
Compliance for Class A ITE products: EU (EMC Directive), USA (FCC Rules), Canada (ICES), Australia (ACMA), New Zealand (RSM), China (CCC), Japan (VCCI), Korea (MSIP), Russia (EAC) |
| Safety |
USA and Canada (UL certified), EU (LVD and EN 60950-1 compliant), Russia (EAC), Singapore (PSB), China (CCC), Argentina (IRAM), Mexico (NYCE), Korea (KC) |
| Compatibility |
HP DesignJet T600 Printer Series; HP DesignJet T790 Printer series; HP DesignJet T795 Printer; HP DesignJet T920 Printer series; HP DesignJet T930 Printer series; HP DesignJet T940 Printer; HP DesignJet T1300 PostScript® Printer; HP DesignJet T1500 Printer series; HP DesignJet T1530 Printer series; HP DesignJet T1600 Printer; HP DesignJet T1700 Printer series; HP DesignJet T2500 Multifunction Printer series; HP DesignJet T2530 Multifunction Printer series; HP DesignJet T2600 Multifunction Printer series; HP DesignJet T3500 Production Multifunction Printer; HP DesignJet XL 3600 Multifunction Printer; HP PageWide XL 39x0, 4x00, 5x00, 6x00, 8x00 Printers; HP DesignJet Z6/Z9+ PostScript® Printer series; HP DesignJet Z6/Z9+ Pro Printer series; HP DesignJet Z5200 Photo Printer; HP DesignJet Z5400 PostScript® Printer; HP DesignJet Z5600 PostScript® Printer; HP DesignJet Z6610 Production Printer; HP DesignJet Z6810 Production Printer series |
| Connectivity, standard |
Gigabit Ethernet (1000Base-T), USB 3.1 gen 1 (3+1) and USB 2.0 (1) rear |
| Interface |
15.6" (396-mm) large touchscreen to preview and enhance images |
| Network ready |
Standard |
| Copier settings |
Print mode, output size, paper type, copies, page order, collate, printer output destination (folder, stacker, bin), folding style selection (only available when folder accessory is available and supported by the HP large-format printer), paneling, tiling, nesting, reprint |
| Acoustic pressure emissions |
62 dB(A) (operating), |
| Non-Operating Humidity Range |
0 to 95% RH |
| Operating humidity range |
20 to 80% RH |
| Operating temperature range |
41 to 95ºF |
| Country of origin |
China(ABG, ACJ, BCD, B19, B1K); Singapore(B1K) |
| Why to buy |
Equip production environments with the powerful HP SD Pro 2 44-in Scanner. Produce large-format scans up to 44-in (1118-mm) wide. CIS scanning technology/1200 dpi provide accurate, high-quality results. Feature enhancements streamline workflows. |
| Headline |
Work effectively with a seamless, secure workflow. This scanner integrates perfectly with HP printers, simplifying maintenance of the complete solution. Avoid reprints with intuitive touchscreen. Secure your workflow with advanced security features. |
| Key selling point |
Accomplish more with incredible speeds—scan 9 inches/sec (22.8 cm/sec) in color, 18 inches/sec (45.7 cm/sec) in grayscale.[1] |
| Image legal disclaimer |
Product image may differ from actual product |
| Product logos |
ENERGY STAR®; EPEAT; Intel Inside Core i5 |
| Taxonomy |
Scanners and Fax |
| Functions |
Copy, scan |
| Model size |
1118 mm |
| Printer drivers included |
Windows drivers for compatible HP PageWide XL and HP DesignJet Printers |
| Media width, maximum |
1168 mm |
| Overview |
Empower production workflows with the high-speed, high-quality HP SD Pro 2 44-in Scanner. Produce scans with crisp lines and fine detail with CIS technology. Enhanced features enable workflow efficiencies that speed up collaboration and outcomes. |
| Company |
HPI |
| Code name |
Pixie |
| Product long name |
HP SD Pro 2 44-in Scanner |
| Bit depth |
48-bit/16-bit |
| Product classification flag |
Standard HP Product |
| Media types |
Non-abrasive paper, sepia, blueprints, plastic, plastic laminate, foam board, cardboard, newspaper (no plywood, stone plates, metal plates or abrasive, dirty, rough, sharp edged, metal clamped, or burned surfaces or transparencies) |
| Tangible flag |
Y |
| Ideal for |
Reproducing documents in full detail and building a multifunction system—seamless integration with HP DesignJet printers and HP PageWide XL printers. |
| Material Type for item |
FERT |
