SKU: 5HB12H
HP DesignJet Studio 24-in Printer with 3-year Warranty
- Print technology
- Ink
- Memory
- 1 GB
Contact us for pricing
Key features
- Touchscreen
- Automatic document feeder
- Front USB flash drive port
- Automatic horizontal cutter
- Stand
Technical specifications
Product
| UPC number | 196548501700 |
|---|---|
| Product type | Office Printers for CAD and GIS |
| Subcategory | Large format |
| UNSPSC code | 43212104 |
Memory
| Memory | 1 GB |
|---|
Storage
| Storage temperature range | -13 to 131ºF |
|---|---|
| Internal Storage | None |
Software
| Software included | HP Click App, HP Click Driver for Windows 11, HP Smart app, HP Print Preview for Windows, HP Easy Start, HP DesignJet Utility for Windows, HP Support Assistant |
|---|
| Print technology | HP Thermal Inkjet |
|---|---|
| Acoustic power emissions (active, printing) | 5.8 B(A) (operating), |
| Print quality color (best) | Up to 2400 x 1200 optimized dpi |
| Print speed | 26 sec/page on A1, 81 A1 prints per hour[1] |
| Printing path | Print Anywhere with HP Smart app, HP Click App, HP Click Driver for Windows 11, HP driver for macOS, HP driver for Windows, printing support for Chrome OS, email printing, HP Print Service Plugin for Android, Apple AirPrint |
Copy and scan
| Copyright notice | © Copyright 2026 HP Development Company, L.P. The information contained herein is subject to change without notice. The only warranties for HP products and services are set forth in the express warranty statements accompanying such products and services. Nothing herein should be construed as constituting an additional warranty. HP shall not be liable for technical or editorial errors or omissions contained herein. |
|---|
Paper handling
| Media size maximum (mm) | 610 |
|---|---|
| Media size maximum (in) | 24 |
| Media sizes standard (metric rolls) | 279 to 610 mm |
| Media sizes standard (sheets, rolls) | 11 to 24 in |
| Media sizes, custom | Auto sheet feeder: 210 x 279 to 330 x 482 mm; manual feed: 210 x 279 to 610 x 1897 mm |
| Media sizes supported | Auto sheet feeder: A4, A3; manual feed: A4, A3, A2, A1 |
Physical
| Color ink technology | Pigment; Dye |
|---|---|
| High capacity of page yield (colour) | 20 ml of ink yields 101 A1/D pages, taking into account maintenance routines[2] |
| Print Cartridge/Bottle, Color(s) | Cyan, magenta, yellow, black |
| Dimensions (W x D x H) | 39.9 x 21.9 x 36.7 in |
| Color or black | Color |
| Roll maximum weight | 4.1 kg |
| Finished output handling | Sheet feed, roll feed, automatic sheet feeder, media bin, automatic horizontal cutter |
| Media weight, recommended | 60 to 280 g/m² (roll/manual feed); 60 to 220 g/m² (auto sheet feeder) |
| Weight | 74.1 lb |
Package
| Package dimensions (W x D x H) | 47.2 x 23.2 x 20.6 in |
|---|---|
| Package weight | 94.8 lb |
Sustainability
| Energy star certified | Yes |
|---|---|
| Environmental certification | ENERGY STAR; WEEE; EU RoHS; EAEU RoHS; REACH; ErP |
| Sustainability Impact | ENERGY STAR® |
| Sustainability specifications | Free, convenient HP ink cartridge and printhead recycling with HP Planet Partners; FSC®-certified papers and a range of recyclable HP media with a take-back program; ENERGY STAR® certified |
| Post consumer recycled plastic in hardware by weight of plastic | 10% |
Warranty and service
| Manufacturer Warranty | Three-year limited hardware warranty |
|---|---|
| Supported Primary Applications | Line drawings; Presentations; Renderings |
Other
| What's in the box | HP DesignJet Studio 24-in Printer, printer stand, automatic sheet feeder, roll cover, printhead, introductory ink cartridges, spindle, quick reference guide, setup poster, power cord |
|---|---|
| Power | Input voltage (auto ranging): 100-240 V (±10%), 50/60 Hz (±3 Hz), 1200 mA max |
| Registration required | No |
| Cartridge volume | Less than 130 ml |
| Ink drop | 5.5 pl (C, M, Y); 12 pl (K) |
| Ink types | Dye-based (C, M, Y); pigment-based (K) |
| Number of cartridges | 4 |
| Print Cartridges/Bottle, Number | 4 (C, M, Y, K) |
| Print cartridge/bottle volume | 80 ml (K); 38 ml (K); 29 ml (C, M, Y) |
| Print head nozzles | 1376 |
| Print heads | 1 (cyan, magenta, yellow, black) |
| Primary applications | Office documents and presentations; Engineering and construction documents |
| Sub brand | DesignJet |
| Electromagnetic compatibility | Compliant with Class B requirements, including: USA (FCC rules), Canada (ICES), EU (EMC/RED Directives), Australia (ACMA), New Zealand (RSM), China (CCC), Japan (VCCI); Certified as Class B product: Korea (KCC) |
| Safety | USA and Canada (CSA certified); EU (LVD, EN 60950-1 and EN 62368-1 compliant); Russia, Belarus, Khazakstan (EAC); Ukraine (UA); Singapore (PSB); China (CCC); Argentina (IRAM); India (BIS); Mexico (NYCE) |
| Accessories | B3Q36A HP DesignJet 24-in Spindle;B3Q37A HP DesignJet 36-in Spindle |
| Connectivity | Apple AirPrint™; Ethernet networking; USB; Wireless (Wi-Fi®); Wireless direct printing |
| Connectivity, standard | Gigabit Ethernet (1000Base-T), Hi-Speed USB 2.0, Wi-Fi 802.11a/b/g/n, Wi-Fi Direct |
| Acoustic pressure emissions | 42 dB(A) (operating), |
| Non-Operating Humidity Range | 0 to 95% RH |
| Operating altitude | Up to 9843 ft |
| Operating humidity range | 20 to 80% RH |
| Operating temperature range | 41 to 104ºF |
| Functions | Print only |
| Country of origin | China |
| Why to buy | This is design that meets performance in the world’s easiest large-format plotters.[1] Extreme simplicity helps you save time and print with confidence. Send multiple files in one click.[4] Save time from job prep to final print. |
| Headline | First net carbon neutral HP DesignJet plotter.[2] Save time with the world's easiest job submission[3] tool - HP Click.[4] Manage your large-format printing virtually anywhere and anytime with the HP Smart app. 1 GB memory. Includes printer stand. |
| Key selling point | Get high-quality results—HP Bright Office Inks plot up to 31% more line accuracy and up to 65% more gamut.[5] |
| Image legal disclaimer | Product image may differ from actual product |
| Product logos | AirPrint; Carbon Neutral; ENERGY STAR; Gold IPv6 Ready; Hi-Speed USB; Wi-Fi CERTIFIED; Windows 10 Compatible |
| Monthly printed pages | Occasionally |
| Taxonomy | Large Format Printers/ Plotters |
| Segment | Business |
| Non-printable area (cut-sheet) | 0.2 x 0.2 x 0.2 x 0.7 in (manual feed); 0.2 x 0.2 x 0.2 x 0.2 in (input tray) |
| Non-printable area (roll media) | 0.2 x 0.2 x 0.2 x 0.2 in |
| Maximum optical density (black) | 8 L* min/2.10 D[4] |
| Line accuracy | ±0.1%[3] |
| Model size | 610 mm |
| Printer drivers included | Raster driver for Windows and macOS, HP Click Driver for Windows 11 |
| Print languages | HP-GL/2, HP-RTL, CALS G4, JPEG, URF |
| Theoretical minimum line width | 0.0008 in |
| Maximum roll diameter | 3.9 in |
| Media thickness | Up to 11.8 mil |
| Printer Applications | Architecture; Engineering; Construction; Technical documents |
| Recommended media | HP Universal Bond Paper (FSC® certified)[5] (recyclable)[6];HP Coated Paper (FSC® certified)[5] (recyclable)[6];HP Heavyweight Coated Paper (FSC® certified)[5] (recyclable)[6] |
| Roll maximum input | 1 |
| Roll size | Up to 24 in |
| Product Disclaimer | Certain HP printers are intended to work only with cartridges that have a new or reused HP chip or electronic circuitry. These printers use dynamic security measures to block cartridges using a non-HP chip or electronic circuitry. Periodic firmware updates will maintain the effectiveness of these measures and block cartridges that previously worked. Reused HP chips and electronic circuitry enable the use of reused, remanufactured, and refilled cartridges. |
| Dynamic security | Dynamic security enabled printer |
| Overview | Featuring a modern office design that compliments its environment and performance to match. Print multi-size jobs easily with auto switching between roll and tray. Enjoy high-speed printing as fast as 26 sec per A1/D plot. 1 GB memory. |
| Company | HPI |
| Code name | Greta |
| Product long name | HP DesignJet Studio 24-in Printer with 3-year Warranty |
| Short product name | Studio |
| Product classification flag | Standard HP Product |
| Media thickness maximum (metric) | Up to 0.3 mm |
| Media types | Bond and coated paper (bond, coated, heavyweight coated, plain, bright white, blueprint), technical paper (natural tracing), film (clear, matte), photographic paper (satin, gloss, semigloss, polypropylene), self-adhesive (adhesive, polypropylene) |
| Tangible flag | Y |
| Ideal for | Ideal for: AEC ecosystem professionals (architects, engineers, construction, subcontractors) focused on creativity, design and sensitive to aesthetics. |
| Material Type for item | FERT |
Notes and footnotes
- [1] The HP DesignJet Studio Printer series and the HP DesignJet T600 Printer series are the only solutions providing seamless printing of both large- and small-format sheets automatically in a multi-size print basket compared to competitive alternatives with comparable size and features as of January, 2020.
- [2] HP is reducing the carbon footprint of printing through carbon reduction initiatives such as energy efficiency, reduced packaging, and use of recycled plastics. The HP DesignJet Studio Printer is the first HP DesignJet where HP has offset the remaining carbon impact due to raw material extraction and processing, printer manufacturing and transportation, as well as electricity, paper, and cartridge use in accordance with The CarbonNeutral Protocol https://www.carbonneutral.com/how/carbonneutral-protocol.
- [3] Three-click printing with HP Click software compared to up to 11 clicks with competitive alternatives when printing 5 files of different sizes. Applicable to PDF, JPEG, TIFF, DWF, and HP-GL/2 files. Based on testing the HP DesignJet Studio 36-in Printer, from job prep to print is up to 2x faster than competitive alternatives with comparable size and features as of January, 2020.
- [1] Mechanical printing time. Printed in Fast mode with Economode on, using HP Bright White Inkjet Paper (bond) and Original HP inks. Actual performance may vary based on a variety of conditions, including but not limited to network configuration.
- [4] One-click printing with HP Click software. Applicable to PDF, JPEG, TIFF, DWF, and HP-GL/2 files.
- [5] Up to 31% more line accuracy based on HP internal testing, September 2019 of 1 pixel vertical line straightness comparing prints from the HP DesignJet Studio Printer series and Canon TM-305 Printer on plain paper using equivalent fast/draft print modes. Up to 65% more color gamut based on HP internal testing, September 2019, of gamut volume comparing prints from the HP DesignJet Studio Printer series and Canon TM-305 Printer on Oce 75gsm plain paper using equivalent fast/draft print modes.
- [2] Calculation done taking into account two normal printhead cleanings and ink on an A1/D CAD drawing with black and color lines and a pixel coverage of 5.2%.
- [3] ±0.1% of the specified vector length or ±0.2 mm (whichever greater) at 23ºC (73ºF), 50-60% relative humidity, on A0/E printing material in Best or Normal mode with HP Heavyweight Coated roll feed and Original HP inks.
- [4] With HP Premium Instant Dry Photo Gloss media with Original HP inks.
- [5] BMG trademark license code FSC®-C115319, see http://www.fsc.org. HP trademark license code FSC®-C017543, see http://www.fsc.org.
- [6] Can be recycled through commonly available recycling programs.
