Key features
- Easily manage your environment
- Single-cable solution
- Small footprint
- Efficient firmware updates
Technical specifications
Product
| UPC number | (ACJ) 193905208647; (UUF) 193905208661 |
|---|---|
| Product type | Docking Stations |
| UNSPSC code | 43211602 |
Display
| Displays supported | Dual monitor |
|---|---|
| Display support | Up to 3 displays supported |
Ports
| External I/O ports | USB Type-A; HDMI; DisplayPort; RJ-45; USB Type-C? power delivery |
|---|---|
| Ports | Front: 1 USB-C® port with data and power out (15W); 1 USB-C® cable to connect to host system Side: 2 USB 3.0 charging ports; 1 combo audio jack Back: 2 USB 3.0 charging ports; 2 DisplayPort™ ports; 1 RJ45 port; 1 HDMI 2.0 port; 1 standard lock slot |
Software
| Compatible Operating Systems | Windows 10; Windows 11; macOS; Chrome OS™ |
|---|
Copy and scan
| Copyright notice | © Copyright 2026 HP Development Company, L.P. The information contained herein is subject to change without notice. The only warranties for HP products and services are set forth in the express warranty statements accompanying such products and services. Nothing herein should be construed as constituting an additional warranty. HP shall not be liable for technical or editorial errors or omissions contained herein. |
|---|
Physical
| Dimensions (W x D x H) | 12.2 x 12.2 x 4.5 cm |
|---|---|
| Weight | 0.75 kg |
Package
| Master carton dimension (metric) | 48.3 x 39.2 x 17.5 cm |
|---|---|
| Package dimensions (W x D x H) | 19.2 x 15.6 x 16.5 cm |
| Master carton weight (metric) | 8.94 kg |
| Package weight | 1.49 kg |
Sustainability
| Energy Usage CO2e (kg) | 6 |
|---|---|
| End of Life CO2e (kg) | 0.1 |
| Production CO2e (kg) | 7 |
| Total CO2e (kg) | 10 |
| Transportation CO2e (kg) | 0.3 |
Warranty and service
| Manufacturer Warranty | 1 Year Limited Warranty (Return to HP/Dealer - Standard Bench Repair & Phone-in Assistance) |
|---|
Other
| Minimum System Requirements | USB Type-C®? (USB Power Delivery, Alt Mode DisplayPort™) |
|---|---|
| What's in the box | HP USB-C® Dock G5; AC Adapter; AC Power cord; Product notices; Warranty; Quick Start guide |
| Power | Power to system: Up to 100W via USB-C® Power to host (USB-C PD): 5V , 9V, 10V, 12V, 15V, 20V all at 5A MAX |
| Registration required | No |
| Brand | HP |
| Compatibility disclaimer 1 | Separate AC needed for HP ZBooks that require more than 100W power delivered via USB-C. HP EliteBook 1050 G1 requires a separate AC adapter. |
| Compatibility disclaimer 2 | Dock power button will not work on Chromebooks. |
| Compatibility disclaimer 3 | Provides up to 100 W via USB-C. |
| Compatibility disclaimer 4 | Power not supported on Mobile Workstation Laptops. |
| Compatibility | Compatible with HP laptops, MacBook® computers, and other laptops.[2] |
| Connector type | USB Type-C? |
| Video connectors | HDMI; DisplayPort™-out; USB Type-C® |
| Country of origin | China(ABY, AB1, UUZ, ABG, UUF, ABU, AR6, ABZ, ACQ, ABJ, ABM, AB0, AB2, AC4, ACJ, ABB, AC8, ABT); Mexico(ABA); Thailand(ABY, AR6, ABZ, ACQ, AC4, ACJ, AC8) |
| Headline | Compatibility without constraints |
| Key selling point | Designed with universal compatibility in mind, this dock works with both HP and non-HP USB-C®- and Thunderbolt™-enabled laptops.[1] |
| Key selling point for SEO | Compatible with most devices and OS |
| Legal disclaimer | Thunderbolt is a trademark of Intel Corporation or its subsidiaries in the U.S. and/or other countries. USB Type-C™ and USB-C™ are trademarks of USB Implementers Forum. Apple is a trademark of Apple Computer, Inc., registered in the U.S. and other countries. |
| Segment | Business |
| User type | Office & Home work; Everyday home |
| Overview | Connect your USB-C®-enabled laptop to your displays, accessories, and wired network with the versatile, elegant, and space-saving HP USB-C® Dock G5. |
| Company | HPI |
| Code name | Adicora-A |
| Product long name | HP USB-C Dock G5 |
| Product subgroup | Docking |
| Security management | 1 Lock slot (side, lock is sold separately) |
| Product classification flag | Standard HP Product |
| Tangible flag | Y |
| Material Type for item | FERT |
Notes and footnotes
- [1] For USB-C® functionality, host PC must support the DisplayPort™ Alt mode protocol through its USB-C® port. Thunderbolt™-enabled notebooks will function at USB-C® speeds. Charging and port replication is supported on notebooks that have implemented USB-C® industry specifications. Power button to turn on or wake the system, on HP notebooks. HP does not provide Ethernet and audio drivers on Mac PCs.
- [2] Based on HP internal testing on select non-HP notebook models compatible with USB-C® industry standards. Certain Alt mode features are not supported, such as power button. Visit the HP Support page to determine your HP notebook's wattage and port specifications. Visit the support page of your non-HP notebook to determine its wattage and port specifications.
- [3] Capable of supporting all three display outputs at the same time.
- [4] Internet connection required and sold separately. Managed PC must be running Windows 10.
- [5] HP includes a one-year limited warranty with online support available 24x7. Consult the HP Customer Support Center for details, or go to www.hp.com/go/orderdocuments. Internet access required and not included.
