Technical specifications
Product
| Product type | Stands |
|---|---|
| UNSPSC code | 43212002 |
Display
| Compatible display sizes | 21.45-31.5" |
|---|
Copy and scan
| Copyright notice | © Copyright 2026 HP Development Company, L.P. The information contained herein is subject to change without notice. The only warranties for HP products and services are set forth in the express warranty statements accompanying such products and services. Nothing herein should be construed as constituting an additional warranty. HP shall not be liable for technical or editorial errors or omissions contained herein. |
|---|
Physical
| Monitor weight capacity (metric) | 2.5-6.8 kg |
|---|---|
| Dimensions (W x D x H) | 54.9 x 32.7 x 11.5 cm |
| Weight | 3.17 kg |
Package
| Master carton dimension (metric) | 50 x 36.5 x 37.7 cm |
|---|---|
| Package dimensions (W x D x H) | 48.2 x 35 x 11.5 cm |
| Cartons per pallet | 12 |
| Layers per pallet | 2 |
| Products per pallet | 36 |
| Products per pallet layer | 18 |
| Master carton weight (metric) | 0.95 kg |
| Package weight | 4.19 kg |
| Pallet weight | 20 kg |
Sustainability
| Environmental certification | Recycled materials? |
|---|---|
| Sustainability specifications | 75% ITE-derived closed loop plastic; Contains ocean-bound plastic; Molded paper pulp cushion inside box is 100% sustainably sourced and plastic cushion inserts contain 80% recycled content |
Warranty and service
| Manufacturer Warranty | HP standard one-year limited warranty |
|---|---|
| Desk thickness support | 10-50 mm |
| Grommet hole size support | 40-80 mm |
Other
| What's in the box | Arm column; Grommet kit; Desk clamp; M4 x L10 mm Thumb screw (4); Allen Key (2), in box and in arm column; VESA kit; Velcro; Quick setup poster; Warranty card |
|---|---|
| Registration required | No |
| Brand | HP |
| pivot | 90° clockwise and counterclockwise |
| Tilt | –5 to +20° |
| VESA mounting | Compatible with 100 mm x 100 mm VESA mount |
| Country of origin | China |
| Headline | Customize your Comfort |
| Key selling point | Get to working comfortably in a snap with the effortless quick release attach for select E-Series G5[1], Series 5 Pro[2], and Series 7 Pro[3] monitors. For other monitors, simply use the VESA mounting bracket. |
| Key selling point for SEO | Single solution that keeps your monitor in reach and your desk clean |
| Legal disclaimer | Actual product may vary from image shown. |
| Segment | Business |
| User type | Everyday |
| Column height range | 404 mm |
| Hinge swivel range | Front hinge: 100° clockwise and counterclockwise; Back hinge: 154° clockwise and counterclockwise |
| Retract/extend range | 89.2–296.4 mm |
| Cartons per layer | 6 |
| Overview | Enjoy more comfort and space with the HP Quick Release Monitor Arm. Easily mount and quickly release select E-Series G5[1], Series 5 Pro[2], and Series 7 Pro[3] monitors to maximize workday comfort and desk space. |
| Company | HPI |
| Code name | Recliner |
| Product long name | HP Quick Release Monitor Single Arm |
| Product description | HP Quick Release Single Arm |
| Product classification flag | Standard HP Product |
| Special features | Quick Release Mechanism |
| Tangible flag | Y |
| Material Type for item | FERT |
Notes and footnotes
- [1] Compatible with select HP P Series, Series 3 Pro, E Series, Series 5 Pro, and Series 7 Pro monitors. Please check detailed compatibility on accessory datasheet.
- [2] Requires monitor VESA adapter for selected models. Please contact your Sales agent or HP Service for further guidance.
- [3] Compatible with monitors that have 100 x 100 VESA mount and adapter. Quick release attach capability is available for the following HP Series 7 Pro monitors: 724pn, 724pf, 724pu, 727pq, 727pu, 727pk and 727pm.
- [1] HP includes a one-year limited warranty with online support available 24x7. Consult the HP Customer Support Center for details, or go to www.hp.com/go/orderdocuments. Internet access required and not included.
- [2] ITE Derived Closed Loop Plastic percentage is based on the definition set in the IEEE 1680.1-2018 standard.
- [3] All plastic parts contain ocean-bound plastic. Percentage of ocean-bound plastic contained in each component varies by product.
- [4] Molded pulp cushions contains 100% recycled wood fiber and organic materials. Plastic cushion contains 80% recycled EPE.
