Key features
- Adjustable stand
- Sustainable
- HP Eye Ease
- WWCB Certified
- 16:10 WUXGA Resolution
- IPS Technology
- 100 Hz Refresh Rate
- More Contrast
- High Brightness
- 100% sRGB Color Gamut
- Progressive White Balance
- Sleek Design, Clean Space
Technical specifications
Product
| UPC number | 197961405064 |
|---|---|
| Product type | Monitors |
Storage
| Storage altitude | Up to 40,000 ft |
|---|
Display
| Aspect ratio | 16:10 |
|---|---|
| Backlight lamp life minimum (to half brightness) | 30,000 hours |
| Brightness | 350 nits |
| Bezel | 3-sided borderless with micro-edge bezel |
| Display area (metric) | 51.84 x 32.4 cm |
| Display colors | Up to 16.7 million colors supported |
| Display contrast ratio (dynamic) | 10000000:1 |
| Display features | Height Adjust/Tilt/Swivel/Pivot |
| Display size (diagonal) | 61 cm (24") |
| Flicker-free | Yes |
| Onscreen controls | Brightness+; Color; Image; Input; Power; Menu; Management; Information; Exit |
| Native resolution | WUXGA (1920 x 1200) |
| Panel bit depth | 8 bit (6 bit + FRC) |
| Panel technology | IPS; LCD |
| Resolution (maximum) | WUXGA (1920 x 1200 @ 100 Hz? |
| Resolutions supported | 640 x 480 @ 60 Hz; 640 x 480 @ 75 Hz; 720 x 400 @ 70 Hz; 800 x 600 @ 60 Hz; 800 x 600 @ 75 Hz; 1024 x 768 @ 60 Hz; 1280 x 720 @ 60 Hz; 1280 x 1024 @ 60 Hz; 1440 x 900 @ 60 Hz; 1600 x 900 @ 60 Hz; 1680 x 1050 @ 60 Hz; 1920 x 1080 @ 50 Hz; 1920 x 1080 @ 60 Hz; 1920 x 1080 @ 100 Hz; 1920 x 1200 @ 60 Hz; 1280 x 1024 @ 75 Hz; 720 x 480 @ 60 Hz; 720 x 576 @ 50 Hz; 1024 x 768 @ 75 Hz; 1280 x 720 @ 50 Hz; 1280 x 720 @ 100 Hz; 1280 x 800 @ 60 Hz; 1920 x 1080 @ 75 Hz; 1920 x 1200 @ 75 Hz; 1920 x 1200 @ 100 Hz |
| Screen treatment | Anti-glare |
| Maximum resolution | 1920 x 1200 (WUXGA) |
| Resolution | WUXGA |
| Screen size (cm) | 61 |
| Screen size range | 23 - 25 |
| Screen size (in) | 24 |
Camera and audio
| Camera | No integrated camera |
|---|
Ports
| Ports | HDMI; USB hub; DisplayPort |
|---|---|
| DisplayPort™ | 1 DisplayPort™ 1.2 |
| HDMI | 1 HDMI 1.4 |
| USB Type-A | 4 USB Type-A 5Gbps signaling rate (1 charging) |
| Usb b (hub enablement) | 1 USB-B |
Battery and power
| Power supply type | Internal |
|---|
Software
| Management Software | HP Display Center; HP Client Management Script Library |
|---|
Copy and scan
| Display scan frequency (horizontal) | 30-130 kHz |
|---|---|
| Display scan frequency (vertical) | 50-100 Hz |
Physical
| Product color | Jet black bezel; Jet black rear cover |
|---|---|
| Stand color | Silver; Jet black |
| Dimensions (W x D x H) | 53.28 x 4.7 x 34.29 cm (without stand) |
| Dimensions With Stand (W x D x H) | 53.28 x 18.95 x 51.75 cm |
| Color gamut | 100% sRGB |
Package
| Package dimensions (W x D x H) | 62.1 x 14 x 41.1 cm |
|---|
Sustainability
| Energy star certified | ENERGY STAR® certified |
|---|---|
| Environmental certification | ENERGY STAR® certified; EPEAT® registered; Low halogen; Recycled Material; TCO Certified; TCO Certified Edge |
| EPEAT registered | EPEAT registered with Climate+ |
| Sustainability specifications | At least 85% ITE-derived closed loop plastic; Contains ocean-bound plastic; At least 30% recycled metal including 90% recycled aluminum in the stand; Contains 20% recycled glass in the monitor panel; Molded paper pulp cushion inside box is made of 100% recycled or certified sources; Low halogen; Outside box and corrugated cushions are made of 100% recycled or certified sources |
| Energy Usage CO2e (kg) | 126.909 |
| End of Life CO2e (kg) | 1.457 |
| Production CO2e (kg) | 98.123 |
| Total CO2e (kg) | 228.012 |
| Transportation CO2e (kg) | 1.523 |
Warranty and service
| Manufacturer Warranty | HP three-year limited warranty |
|---|
Other
| What's in the box | Monitor; DisplayPort™ cable; HDMI cable; Warranty card; USB Type-B to A cable; Quick Setup Poster; AC power cord |
|---|---|
| Power consumption | 58 W (maximum), 22 W (typical), 0.5 W (standby) |
| Power | 100 - 240 VAC 50/60 Hz |
| Registration required | No |
| Brand | HP |
| Series name | HP Series 5 Pro 24 inch |
| Sub brand | HP Series 5 Pro |
| Certifications and compliances | BIS; BSMI; CB; CCC; CE; CECP; CEL; cTUVus; EAC; FCC; GS Mark; ICES; ISO 9241-307; KC; KCC; NOM; PSB; RCM; SEPA; TUV-S; VCCI; WEEE; ISC; California Energy Commission (CEC); WW application; UAE; TGM; Ukraine certificates; NRCS; PSE; Ukraine EE; TÜV Low Blue Light Hardware Solution certified; Works with Chromebook certified; Korea MEPS; CEL Grade 2; Australian-New Zealand DoC; EMF |
| TCO Certified | TCO Certified, generation 10; TCO Certified, Edge |
| HDCP | Yes, DisplayPort™ and HDMI |
| Video connectors | HDMI; DisplayPort™-in |
| Base area footprint (metric) | 24.2 x 18.95 cm |
| Backlight type | Edge-lit; WLED |
| Curvature | Flat |
| Contrast ratio | 1500:1 |
| Hardness | 3H |
| Haze | 25% |
| Horizontal viewing angle | 178° |
| Low blue light | HP Eye Ease (TÜV Low Blue Light Hardware Solution certified) |
| pivot | ±90° |
| Pixel pitch | 0.27 x 0.27 mm |
| Pixels per inch (ppi) | 94 ppi |
| Refresh rate (maximum) | 100 Hz |
| Response time (typical) | 5ms GtG (with overdrive) |
| Stand type | Base stand; With stand; Height adjustable stand |
| Swivel | ±45° |
| Tilt | -5 to +23° |
| VESA mounting | 100 x 100 mm |
| Viewable diagonal size | 24" (61.13 cm) |
| Non-Operating Humidity Range | 5–95% |
| Operating altitude | Up to 16,400 ft |
| Operating humidity range | 20 to 80% RH (non-condensing) |
| Operating temperature range | 41 to 95°F |
| Country of origin | China(AB2, B1L); Vietnam(ABV, ABU, UUF, ACJ, AB1, ABY, A2N, ABJ, ABT, AB0, AKH, AB4, ABG, A2K, UUZ, AH3, AKL, ACQ, AR6, AC8, ABB, ABA) |
| Headline | Elevate your productivity |
| Key selling point | See more of your work and get more done on this 24" WUXGA resolution monitor. A lightning-fast 100 Hz refresh rate[1] brings out every detail. Elevate your view even more by experiencing bright, vibrant, consistent colors with 100% sRGB[1] and HP Progressive White Balance.[2] |
Notes and footnotes
- A product carbon footprint is defined as the total amount of greenhouse gases emitted directly and indirectly by a product over its lifetime. Greenhouse gas emissions are reported as global warming potential for 100-year time horizon (GWP-100) in units of CO2 equivalence. Calculations are done in accordance with ISO 14040 & ISO 14044. Individual values may not sum to total due to rounding.
- [1] All performance specifications represent the typical specifications provided by HP's component manufacturers; actual performance may vary, either higher or lower.
- [2] HP's Progressive White Balance feature is designed to calibrate 100% full white on HP Series 5 Pro monitors. This adjustment is intended to align the white point more closely among various HP Series 5 Pro monitors. However, due to the nature of monitors, perceptible differences in the white color may still occur when the monitors are viewed from varying angles.
- [3] Dock sold separately. Both HP Series 5 Pro 24" WUXGA - 524pn monitors need to be connected to the dock for a dual display setup.
- [1] All specifications represent the typical specifications provided by HP's component manufacturers, actual performance may vary either higher or lower.
- [4] HP Series 5 Pro 24" WUXGA - 524pn monitor sold separately.
- [5] Ergonomic Setup Guide is available through HP Display Center. Host PC requires Windows 10 or higher. HP Display Center is available on the Microsoft store.
- [2] DisplayPort™ 1.2 or HDMI 1.4 required to drive panel at its native resolution. The video card of the connected PC must be capable of supporting 1920 x 1200 at 60 Hz with 8-bit color using one DisplayPort™, HDMI. The video card of the connected PC must be capable of supporting 1920 x 1200 and include one DisplayPort™ or one HDMI outputs to drive the monitor at the Preferred Mode.
- [6] Recycled plastic is expressed as a percentage of the total weight plastic. Post-consumer recycled is based on the definition set in the EPEAT® standard for computers, IEEE 1680.1-2018 standard. Recycled metal is expressed as a percentage of the total weight of the metal according to ISO 14021 definitions for metal parts over 25 grams.
- [3] Number of colors through A-FRC technology.
- [7] 100% of paper-based packaging made from sustainably sourced, certified, and recycled fibers.
- [4] Included cables may vary by country.
- [14] Based on internal testing of HP Series 7 Pro and HP Series 5 Pro monitors with USB Type-C® or HDMI connections to devices on macOS and Windows, March 2024 and September 2024. Requires USB Type-C® or HDMI connectivity. Some features may not be supported.
- [5] Lock sold separately.
- [6] Host PC requires Windows 10 and above. HP Display Center is available on the Microsoft store.
- [7] EPEAT® registered where applicable. EPEAT® registration varies by country. See www.epeat.net for registration status by country. Based on US EPEAT® registration according to IEEE 1680.1-2018 EPEAT®. Status varies by country. Visit www.epeat.net for more information.
- [8] External power supplies, WWAN modules, power cords, cables and peripherals excluded. Service parts obtained after purchase may not be Low Halogen.
- [9] Molded pulp cushions are made from 100% recycled wood fiber and organic materials.
- [10] 100% outer box packaging and corrugated cushions made from sustainably sourced certified and recycled fibers.
- [11] Recycled plastic content percentage is based on the definition set in the IEEE 1680.1-2018 standard.
- [12] Recycled metal is expressed as a percentage of the total weight of the metal according to ISO 14021 definitions for metal parts over 25 grams.
- [13] HP's Progressive White Balance feature is designed to calibrate 100% full white on HP Series 5 Pro monitors. This adjustment is intended to align the white point more closely among various HP Series 5 Pro monitors. However, due to the nature of monitors, perceptible differences in the white color may still occur when the monitors are viewed from varying angles.
- [14] Percentage of recycled glass in the monitor panel varies by product. Recycled glass is expressed as a percentage of the total weight of the glass.
- [15] The Client Management Script Library must be downloaded to the connected PC to run CMSL commands. Some limitations may apply to legacy displays. Visit support.hp.com to download HP CMSL.
- [16] Not all features are available in all editions or versions of Windows. Systems may require upgraded and/or separately purchased hardware, drivers, software or BIOS update to take full advantage of Windows functionality. Windows is automatically updated and enabled. High speed internet and Microsoft account required. ISP fees may apply and additional requirements may apply over time for updates. See http://www.windows.com.
- [17] TCO Certified is a ISO 14024 Type 1 sustainability label for IT products. Compliance with all criteria is independently verified.
