SKU: 9D9V7AA
HP Series 5 Pro 23.8 inch FHD USB-C Monitor - 524pu
Contact us for pricing
Key features
- Adjustable stand
- VESA mountable
- Sustainable
- HP Eye Ease
- WWCB Certified
- FHD Resolution
- IPS Technology
- 100 Hz Refresh Rate
- More Contrast
- High Brightness
- 100% sRGB Color Gamut
- Progressive White Balance
Technical specifications
Product
| UPC number | 197961408249 |
|---|---|
| Product type | Monitors |
Display
| Aspect ratio | 16:9 |
|---|---|
| Backlight lamp life minimum (to half brightness) | 30,000 hours |
| Brightness | 350 nits |
| Bezel | 3-sided borderless with micro-edge bezel |
| Display area (metric) | 52.70 x 29.65 cm |
| Display colors | Up to 16.7 million colors supported |
| Display contrast ratio (dynamic) | 10000000:1 |
| Display features | Docking monitor |
| Display size (diagonal) | (23.8) 60.45 cm |
| Onscreen controls | Brightness+; Color; Image; Input; Power; Menu; Management; Information; Exit |
| Native resolution | FHD (1920 x 1080) |
| Panel bit depth | 8 bit (6 bit + FRC) |
| Panel technology | IPS; LCD |
| Resolution (maximum) | FHD (1920 x 1080 @ 100 Hz) |
| Resolutions supported | 640 x 480 @ 60 Hz; 640 x 480 @ 75 Hz; 720 x 400 @ 70 Hz; 800 x 600 @ 60 Hz; 800 x 600 @ 75 Hz; 1024 x 768 @ 60 Hz; 1280 x 720 @ 60 Hz; 1280 x 1024 @ 60 Hz; 1440 x 900 @ 60 Hz; 1600 x 900 @ 60 Hz; 1680 x 1050 @ 60 Hz; 1920 x 1080 @ 60 Hz; 1920 x 1080 @ 100 Hz; 1280 x 1024 @ 75 Hz; 1024 x 768 @ 75 Hz; 1280 x 800 @ 60 Hz; 1920 x 1080 @ 75 Hz |
| Screen treatment | Anti-glare |
| Maximum resolution | 1920 x 1080 (FHD) |
| Resolution | FHD |
| Screen size (cm) | 60.5 |
| Screen size range | 23 - 25 |
| Screen size (in) | 23.8 |
Camera and audio
| Camera | No integrated camera |
|---|
Ports
| Ports | HDMI; USB-C; USB hub; DisplayPort; DisplayPort out |
|---|---|
| DisplayPort™ | 1 DisplayPort™ 1.4 |
| DisplayPort™ Out | 1 DisplayPort™ 1.4-out |
| Ethernet | 1 RJ-45 (10/100/1000 Mbps) |
| HDMI | 1 HDMI 2.0 |
| USB Type-A | 3 USB Type-A 5Gbps signaling rate (1 charging) |
| USB Type-C® data | 1 USB Type-C® 5Gbps signaling rate (Up to 15W USB Power Delivery) |
| USB Type-C® video input | 1 USB Type-C® 5Gbps signaling rate (Up to 100W USB Power Delivery, Alt Mode DisplayPort™ 1.4) |
Battery and power
| Power supply type | Internal |
|---|
Software
| Management Software | HP Display Center; HP Client Management Script Library |
|---|
Copy and scan
| Display scan frequency (horizontal) | 30-115 kHz |
|---|---|
| Display scan frequency (vertical) | 50-100 Hz |
Physical
| Product color | Jet black |
|---|---|
| Stand color | Jet black; Natural silver |
| Dimensions (W x D x H) | 21.24 x 1.86 x 12.37 in (without stand) |
| Product dimensions with stand (W x D x H) | 21.24 x 7.46 x 19.81 in |
| Dimensions With Stand (W x D x H) | 53.94 x 18.95 x 50.32 cm |
| Color gamut | 100% sRGB |
Package
| Package dimensions (W x D x H) | 24.45 x 5.51 x 15.47 in |
|---|
Sustainability
| Energy star certified | ENERGY STAR® certified |
|---|---|
| Environmental certification | ENERGY STAR® certified; EPEAT® registered; Low halogen; Recycled Material; TCO Certified; TCO Certified Edge |
| EPEAT registered | EPEAT registered with Climate+ |
| Sustainability specifications | At least 85% ITE-derived closed loop plastic; Contains ocean-bound plastic; At least 40% recycled metal including 90% recycled aluminum in the stand; Contains 20% recycled glass in the monitor panel; Molded paper pulp cushion inside box is made of 100% recycled or certified sources; Low halogen; Outside box and corrugated cushions are made of 100% recycled or certified sources |
| Energy Usage CO2e (kg) | 159.02 |
| End of Life CO2e (kg) | 1.702 |
| Production CO2e (kg) | 115.715 |
| Total CO2e (kg) | 278.036 |
| Transportation CO2e (kg) | 1.599 |
Warranty and service
| Manufacturer Warranty | HP three-year limited warranty |
|---|
Other
| What's in the box | Monitor; Warranty card; AC power cable; Quick Setup Poster; 1 USB Type-C® to Type-C cable |
|---|---|
| Power consumption | 198 W (maximum), 22 W (typical), 0.5 W (standby) |
| Power | 100 - 240 VAC 50/60 Hz |
| Registration required | No |
| Brand | HP |
| Series name | HP Series 5 Pro 23.8 inch |
| Sub brand | HP Series 5 Pro |
| Certifications and compliances | Australian-New Zealand MEPS; BIS; BSMI; CB; CCC; CE; CECP; CEL Grade 1; cTUVus; EAC; FCC; ICES; ISO 9241-307; KC; KCC; NOM; PSB; RCM; SEPA; TUV-S; VCCI; Vietnam MEPS; WEEE; ISC; California Energy Commission (CEC); UAE; TGM; Ukraine certificates; TÜV Flicker free certified; NRCS; PSE; GS; Ukraine EE; TÜV Low Blue Light Hardware Solution certified; Korea MEPS; Australian-New Zealand DoC; EMF |
| TCO Certified | TCO Certified, generation 10; TCO Certified, Edge |
| HDCP | Yes, DisplayPort™, HDMI and USB Type-C® |
| Video connectors | HDMI; DisplayPort™-in; DisplayPort™-out; USB Type-C® |
| Base area footprint (metric) | 24.2 x 18.95 cm |
| Backlight type | Edge-lit; WLED |
| Curvature | Flat |
| Detachable stand | Yes |
| Contrast ratio | 1500:1 |
| Hardness | 3H |
| Haze | 25% |
| Horizontal viewing angle | 178° |
| Low blue light | HP Eye Ease (TÜV Low Blue Light Hardware Solution certified) |
| pivot | ±90° |
| Pixel pitch | 0.28 x 0.28 mm |
| Pixels per inch (ppi) | 93 ppi |
| Refresh rate (maximum) | 100 Hz |
| Response time (typical) | 5ms GtG (with overdrive) |
| Stand type | Base stand; With stand; Height adjustable stand |
| Swivel | ±45° |
| Tilt | -5 to +23° |
| VESA mounting | 100 x 100 mm |
| Viewable diagonal size | 23.8" (60.47 cm) |
| Non-Operating Humidity Range | 5 – 95% |
| Operating humidity range | 20 to 80% RH (non-condensing) |
| Operating temperature range | 41 to 95°F |
Notes and footnotes
- A product carbon footprint is defined as the total amount of greenhouse gases emitted directly and indirectly by a product over its lifetime. Greenhouse gas emissions are reported as global warming potential for 100-year time horizon (GWP-100) in units of CO2 equivalence. Calculations are done in accordance with ISO 14040 & ISO 14044. Individual values may not sum to total due to rounding.
- [1] All performance specifications represent the typical specifications provided by HP's component manufacturers; actual performance may vary, either higher or lower.
- [2] HP's Progressive White Balance feature is designed to calibrate 100% full white on HP Series 5 Pro monitors. This adjustment is intended to align the white point more closely among various HP Series 5 Pro monitors. However, due to the nature of monitors, perceptible differences in the white color may still occur when the monitors are viewed from varying angles.
- [3] Works across any OS. Keeps the same power delivery when connecting multiple devices.
- [1] All specifications represent the typical specifications provided by HP's component manufacturers, actual performance may vary either higher or lower.
- [4] 100 Hz refresh rate supported on host PCs with DisplayPort™ 1.2 or higher. Host PC may affect the refresh rate combinations of monitors 1 and 2. Refresh rates can be user enabled in PC settings.
- [5] HP Series 5 Pro monitor or additional monitor sold separately.
- [2] DisplayPort™ 1.4 or HDMI 2.0 required to drive panel at its native resolution. The video card of the connected PC must be capable of supporting 1920 x 1080 at 60 Hz with 8-bit color using one DisplayPort™, HDMI. The video card of the connected PC must be capable of supporting 1920 x 1080 and include one DisplayPort™ or one HDMI outputs to drive the monitor at the Preferred Mode.
- [6] Ergonomic Setup Guide is available through HP Display Center. Host PC requires Windows 10 or higher. HP Display Center is available on the Microsoft store.
- [3] Number of colors through A-FRC technology.
- [7] Host PC requires Windows 10 or higher. HP Display Center is available for download on the Microsoft store for Windows or support.hp.com for Windows and MacOS.
- [4] Included cables may vary by country.
- [8] Recycled plastic is expressed as a percentage of the total weight plastic. Post-consumer recycled is based on the definition set in the EPEAT® standard for computers, IEEE 1680.1-2018 standard.
- [5] Lock sold separately.
- [9] Recycled metal is expressed as a percentage of the total weight of the metal according to ISO 14021 definitions for metal parts over 25 grams.
- [6] Host PC requires Windows 10 and above. HP Display Center is available on the Microsoft store.
- [10] Percentage of recycled glass in the monitor panel varies by product. Recycled glass is expressed as a percentage of the total weight of the glass.
- [7] EPEAT® registered where applicable. EPEAT® registration varies by country. See www.epeat.net for registration status by country. Based on US EPEAT® registration according to IEEE 1680.1-2018 EPEAT®. Status varies by country. Visit www.epeat.net for more information.
- [11] 100% of paper-based packaging made from sustainably sourced, certified, and recycled fibers.
