SKU: 9E0Z2UT
HP Series 5 Pro 34 inch WQHD USB-C Conferencing Monitor - 534pm
Contact us for pricing
Key features
- Adjustable stand
- Curved display
- Integrated speakers
- VESA mountable
- Webcam
- Sustainable
- HP Eye Ease
- Ambient light sensor
- Sharp & Privacy Ready 5MP Webcam
- AI Noise Reduction
- Intuitive Conferencing Experience
- Integrated 4 x 3W Down Firing Speakers
Technical specifications
Product
| UPC number | 198122896240 |
|---|---|
| Product type | Monitors |
Display
| Max video resolution | 2592 x 1944 at 30 fps |
|---|---|
| Aspect ratio | 21:9 |
| Backlight lamp life minimum (to half brightness) | 30,000 hours |
| Brightness | 400 nits |
| Bezel | 3-sided borderless |
| Display area (metric) | 79.72 x 33.37 cm |
| Display colors | Up to 16.7 million colors supported |
| Display contrast ratio (dynamic) | 10,000,000:1 |
| Display features | Docking monitor |
| Display size (diagonal) | 86.4 cm (34") |
| Flicker-free | Yes (TÜV certified) |
| Onscreen controls | Color; Image; Input; Audio; Power; Menu; Management; Information; Exit; Split screen |
| Native resolution | WQHD (3440 x 1440) |
| Panel bit depth | True 8 bit |
| Panel technology | VA; LCD |
| Resolution (maximum) | WQHD (3440 x 1440 @ 100 Hz) |
| Resolutions supported | 640 x 480 @ 60 Hz; 640 x 480 @ 75 Hz; 720 x 400 @ 70 Hz; 800 x 600 @ 60 Hz; 800 x 600 @ 75 Hz; 1024 x 768 @ 60 Hz; 1280 x 720 @ 60 Hz; 1280 x 1024 @ 60 Hz; 1440 x 900 @ 60 Hz; 1600 x 900 @ 60 Hz; 1680 x 1050 @ 60 Hz; 1920 x 1080 @ 60 Hz; 1920 x 1200 @ 60 Hz; 2560 x 1440 @ 60 Hz; 2560 x 1440 @ 75 Hz; 2560 x 1440 @ 100 Hz; 1280 x 1024 @ 75 Hz; 3440 x 1440 @ 60 Hz; 3440 x 1440 @ 75Hz; 3440 x 1440 @ 100 Hz; 1024 x 768 @ 75 Hz; 1280 x 800 @ 60 Hz; 1920 x 1080 @ 75 Hz |
| Screen treatment | Anti-glare |
| Maximum resolution | 3440 x 1440 (WQHD) |
| Resolution | WQHD |
| Screen size (cm) | 86.4 |
| Screen size range | > 27 |
| Screen size (in) | 34 |
Camera and audio
| Camera | 5 MP camera |
|---|---|
| Camera features | Independent tilt -20° to 5°; Windows Hello support (IR Sensor); Pop-up privacy; Auto Lock and Awake |
| Audio port | 1 x 3.5 mm Audio Jack (Audio In/Out Combo) |
Ports
| Ports | HDMI; USB-C; USB hub; DisplayPort |
|---|---|
| DisplayPort™ | 1 DisplayPort™ 1.4 |
| Ethernet | 1 RJ-45 (10/100/1000 Mbps) |
| HDMI | 1 HDMI 2.0 |
| USB Type-A | 3 USB Type-A 5Gbps signaling rate (1 charging) |
| Usb b (hub enablement) | 1 USB-B |
| USB Type-C® data | 1 USB Type-C® 5Gbps signaling rate (Up to 15W USB Power Delivery) |
| USB Type-C® video input | 1 USB Type-C® 5Gbps signaling rate (Up to 100W USB Power Delivery, Alt Mode DisplayPort™ 1.4) |
Battery and power
| Power supply type | Internal |
|---|
Software
| Certified collaboration software | Zoom |
|---|---|
| Management Software | HP Display Center; HP Client Management Script Library |
Copy and scan
| Display scan frequency (horizontal) | 30-155 kHz |
|---|---|
| Display scan frequency (vertical) | 50-100 Hz |
Physical
| Product color | Jet black |
|---|---|
| Stand color | Jet black; Natural silver |
| Dimensions (W x D x H) | 31.81 x 4.59 x 14.52 cm (without stand) |
| Dimensions With Stand (W x D x H) | 80.79 x 26.96 x 54.71 cm |
| Color gamut | 99% sRGB |
Package
| Package dimensions (W x D x H) | 91.1 x 22.5 x 46.5 cm |
|---|
Sustainability
| Energy star certified | ENERGY STAR® certified |
|---|---|
| Environmental certification | ENERGY STAR® certified; EPEAT® registered; Low halogen; Recycled Material; TCO Certified; TCO Certified Edge |
| EPEAT registered | EPEAT registered with Climate+ |
| Sustainability specifications | At least 85% ITE-derived closed loop plastic; Contains ocean-bound plastic; At least 20% recycled metal including 90% recycled aluminum in the stand; Contains 20% recycled glass in the monitor panel; Low halogen; Outside box and corrugated cushions are made of 100% recycled or certified sources |
| Energy Usage CO2e (kg) | 393.756 |
| End of Life CO2e (kg) | 3.544 |
| Production CO2e (kg) | 222.008 |
| Total CO2e (kg) | 622.673 |
| Transportation CO2e (kg) | 3.365 |
Warranty and service
| Manufacturer Warranty | HP three-year limited warranty |
|---|
Other
| What's in the box | Monitor; DisplayPort™ cable; Warranty card; USB Type-A to B cable; Quick Setup Poster; 1 USB Type-C® to Type-C cable; AC power cord; VESA mount adapter |
|---|---|
| Power consumption | 265 W (maximum), 45 W (typical), 0.5 W (standby) |
| Power | 100 - 240 VAC 50/60 Hz |
| Diagonal field of view (dFoV) | 80° (RGB) |
| Registration required | No |
| Brand | HP |
| Series name | HP Series 5 Pro 34 inch |
| Sub brand | HP Series 5 Pro |
| Certifications and compliances | BIS; BSMI; CB; CCC; CE; CECP; CEL; cTUVus; EAC; FCC; ICES; ISO 9241-307; KC; KCC; NOM; PSB; RCM; SEPA; TUV-S; VCCI; WEEE; ISC; California Energy Commission (CEC); WW application; UAE; Ukraine certificates; TÜV Flicker free certified; NRCS; PSE; GS; Ukraine EE; TÜV Low Blue Light Hardware Solution certified; Korea MEPS; CEL Grade 2; Australian-New Zealand DoC; EMF |
| TCO Certified | TCO Certified, generation 10; TCO Certified, Edge |
| HDCP | Yes, DisplayPort™, HDMI and USB Type-C® |
| Video connectors | HDMI; DisplayPort™-in; USB Type-C® |
| Base area footprint (metric) | 25.6 x 25.35 cm |
| Backlight type | Edge-lit; WLED |
| Conferencing hot keys | Mic mute; Speaker Mute; Volume up/down |
| Curvature | 1500R |
| Detachable stand | Yes |
| Contrast ratio | 4000:1 |
| Hardness | 3H |
| Haze | 25% |
| Horizontal viewing angle | 178° |
| Low blue light | HP Eye Ease (TÜV Low Blue Light Hardware Solution certified) |
| Pixel pitch | 0.23 x 0.23 mm |
| Pixels per inch (ppi) | 110 ppi |
| Refresh rate (maximum) | 100 Hz |
| Response time (typical) | 5ms GtG (with overdrive) |
| Stand type | Base stand; With stand; Height adjustable stand |
| Swivel | ±30° |
| Tilt | -5 to +20° |
| VESA mounting | 100 x 100 mm |
| Viewable diagonal size | 34" (86.4 cm) |
| Non-Operating Humidity Range | 5 – 95% |
| Operating humidity range | 20 to 80% RH (non-condensing) |
| Operating temperature range | 41 to 95°F |
Notes and footnotes
- A product carbon footprint is defined as the total amount of greenhouse gases emitted directly and indirectly by a product over its lifetime. Greenhouse gas emissions are reported as global warming potential for 100-year time horizon (GWP-100) in units of CO2 equivalence. Calculations are done in accordance with ISO 14040 & ISO 14044. Individual values may not sum to total due to rounding.
- [1] For KVM compatibility, if connected PCs do not have USB-C® port, user will need a USB-B to A cable.
- [2] Recycled plastic is expressed as a percentage of the total weight plastic. Post-consumer recycled is based on the definition set in the EPEAT® standard for computers, IEEE 1680.1-2018 standard.
- [3] Recycled metal is expressed as a percentage of the total weight of the metal according to ISO 14021 definitions for metal parts over 25 grams.
- [1] All performance specifications represent the typical specifications provided by HP's component manufacturers, actual performance may vary either higher or lower.
- [4] Percentage of recycled glass in the monitor panel varies by product. Recycled glass is expressed as a percentage of the total weight of the glass.
- [5] 100% of paper-based packaging made from sustainably sourced, certified, and recycled fibers.
- [2] DisplayPort™ 1.4 or HDMI 2.0 required to drive panel at its native resolution. The video card of the connected PC must be capable of supporting 2560 x 1440 at 60 Hz with 8 bit color using one DisplayPort™, HDMI. The video card of the connected PC must be capable of supporting 2560 x 1440 and include one DisplayPort™ or one HDMI outputs to drive the monitor at the Preferred Mode.
- [13] Based on internal testing of HP Series 7 Pro and HP Series 5 Pro monitors with USB Type-C® or HDMI connections to devices on macOS and Windows, March 2024 and September 2024. Requires USB Type-C® or HDMI connectivity. Some features may not be supported.
- [3] Included cables may vary by country.
- [4] 100% outer box packaging and corrugated cushions made from sustainably sourced certified and recycled fibers.
- [5] ITE Derived Closed Loop Plastic percentage is based on the definition set in the IEEE 1680.1-2018 standard.
- [6] Ocean Bound plastic is based on the definition set by the UL2809 standard.
- [7] Recycled metal is expressed as a percentage of the total weight of the metal according to ISO 14021 definitions for metal parts over 25 grams.
- [8] Percentage of recycled glass in the monitor panel varies by product. Recycled glass is expressed as a percentage of the total weight of the glass.
- [9] Host PC requires Windows 10 and above. HP Display Center is available on the Microsoft store.
- [10] The Client Management Script Library must be downloaded to the connected PC to run CMSL commands. Some limitations may apply to legacy displays. Visit support.hp.com to download HP CMSL.
- [11] Lock sold separately.
- [12] EPEAT® registered where applicable. EPEAT® registration varies by country. See www.epeat.net for registration status by country. Based on US EPEAT® registration according to IEEE 1680.1-2018 EPEAT®. Status varies by country. Visit www.epeat.net for more information.
