SKU: 9E525UCR
HP ZBook Studio 16 inch G10 Mobile Workstation PC (7C9J7AV)
- Display
- 40.6 cm (16") diagonal WQUXGA display
- Graphics
- Integrated
- Memory
- 32 GB DDR5-5600 MHz RAM (2 x 16 GB)
- Processor
- 13th Generation Intel® Core™ i7 processor
Contact us for pricing
Key features
- Fingerprint sensor
- Absolute persistence module
- HP Credential Manager
- HP Power On Authentication
- Master Boot Record security
- Pre-boot authentication
- Windows Defender
- HP Manageability Integration Kit
- HP BIOSphere Gen6
- HP Sure Start Gen6
- HP Sure Admin
- HP Image Assistant
Technical specifications
Product
| UPC number | (ABU) 198990558608; (ABV) 198701432203 |
|---|---|
| Product type | Workstations |
| Subcategory | Laptops; Workstations |
| UNSPSC code | 43211503 |
Processor
| Processor family | 13th Generation Intel® Core™ i7 processor |
|---|---|
| Processor | Intel® Core™ i7-13800H (up to 5.2 GHz with Intel® Turbo Boost Technology, 24 MB L3 cache, 14 cores, 20 threads) |
Memory
| Memory Slots | 2 SODIMM; supports dual channel |
|---|---|
| Memory | 32 GB DDR5-5600 MHz RAM (2 x 16 GB) |
| Standard memory note | Transfer rates up to 5600 MT/s. |
| Memory card device | 1 microSD 7.1 media card reader |
Storage
| Internal Storage | 512 GB PCIe® Gen4 NVMe™ TLC SSD |
|---|---|
| Memory and storage | 32 GB memory; 512 GB SSD storage |
Display
| Display | (16) 40.64 cm diagonal, WQUXGA (3840 x 2400), IPS, anti-glare, micro-edge, 500 nits, 100% DCI-P3, HP DreamColor |
|---|---|
| Screen size (in) | 16 |
Graphics
| Graphics | Integrated |
|---|---|
| Graphics (integrated) | Intel® Iris® X? Graphics |
| Graphics (discrete) | NVIDIA RTX™ A1000 Laptop GPU (6 GB GDDR6 dedicated) |
Camera and audio
| Audio | Audio by Bang & Olufsen, Quad-speaker audio (2 tweeters & 2 Quad woofers), 2 Top Facing Microphone dual array digital microphones, functions keys for volume up and down, combo microphone/headphone jack, HD audio with 200Hz Bass Roll off |
|---|---|
| Camera | 720p HD IR camera |
Keyboard and input
| Keyboard | HP Premium Quiet Keyboard – spill-resistant, full-size keyboard with drain and DuraKeys |
|---|---|
| Pointing device | ClickPad Glass with multi-touch gesture support, taps enabled as default |
Wireless
| Wireless | Intel® Wi-Fi 6E AX211 (2x2) and Bluetooth® 5.3 wireless card, vPro® |
|---|
Ports
| Ports | 1 power connector; 1 headphone/microphone combo; 2 Thunderbolt™ 4 with USB4™ Type-C® 40Gbps signaling rate (USB Power Delivery, DisplayPort™ 1.4, HP Sleep and Charge), 1 Super Speed USB Type-A 5Gbps signaling rate (charging); 1 SuperSpeed USB Type-C® 10Gbps signaling rate (USB Power Delivery, DisplayPort™ 1.4) |
|---|
Battery and power
| Battery recharge time | Supports battery fast charge: approximately 50% in 30 minutes |
|---|---|
| Battery type | HP Long Life 6-cell, 86 Wh Li-ion polymer |
Software
| Available software | HP Smart Support |
|---|---|
| Software included | Bing search for IE11; HP Hotkey Support; HP Noise Cancellation Software; HP Performance Advisor; HP Support Assistant; Native Miracast support; HP Connection Optimizer; myHP; HP Privacy Settings; Data Science Stack; HP Easy Clean; HP PC Hardware Diagnostics; Windows 10 Cloud Recovery Client; HP Z Light Space; HP Camera & Super Resolution Software; HP Services Scan; Microsoft 365 and Office (sold separately and Internet access required for activation); HP Presence |
| Operating system | Windows 11 Pro |
Security
| Fingerprint reader | Fingerprint sensor |
|---|
Copy and scan
| Copyright notice | © Copyright 2026 HP Development Company, L.P. The information contained herein is subject to change without notice. The only warranties for HP products and services are set forth in the express warranty statements accompanying such products and services. Nothing herein should be construed as constituting an additional warranty. HP shall not be liable for technical or editorial errors or omissions contained herein. |
|---|
Physical
| Dimensions (W x D x H) | 35.6 x 24.2 x 1.9 cm (non-touch); 35.6 x 24.2 x 1.8 cm (touch) |
|---|---|
| Weight (kg) | 1.73 |
| Weight | Starting at 1.73 kg |
| Weight note (metric) | Weight varies by configuration and components. |
Package
| Package dimensions (W x D x H) | 21.73 x 2.71 x 13.58 in |
|---|
Sustainability
| Ecolabels | TCO Certified |
|---|---|
| Energy star certified | ENERGY STAR® certified |
| Sustainability specifications | Low Halogen |
| Energy Usage CO2e (kg) | 140.518 |
| End of Life CO2e (kg) | 0.85 |
| Production CO2e (kg) | 224.922 |
| Total CO2e (kg) | 384.454 |
| Transportation CO2e (kg) | 18.164 |
Other
| Power | 200 W external AC power adapter |
|---|---|
| Registration required | No |
| Series name | HP ZBook Studio (16) 40.64 cm G10 |
| Sub brand | ZBook |
| I/O Port location | Right side |
| Family positioning headline | Inspired innovation. |
| Form factor | Mobile workstation |
| Country of origin | China(ABV, ABU) |
| Headline | Pro-grade performance for your biggest projects |
| Key selling point | Enjoy fast, smooth gameplay with an NVIDIA RTX™ professional or GeForce RTX™ GPU.[2] Highlight favorite keys and create custom key maps with Z Light Space software9 and a RGB keyboard with per-key LED backlighting.[8] |
| Image legal disclaimer | Product image may differ from actual product |
| Trademark information | Intel, Core, Optane, Celeron, Pentium, Iris, XMM, and Thunderbolt are trademarks or registered trademarks of Intel Corporation or its subsidiaries in the United States and other countries. AMD, Ryzen, Athlon, and Radeon are trademarks of Advanced Micro Devices, Inc. Bluetooth is a trademark owned by its proprietor and used by HP Inc. under license. NVIDIA and GeForce are trademarks and/or registered trademarks of NVIDIA Corporation in the U.S. and other countries. USB Type-C® and USB-C® are registered trademarks of USB Implementers Forum. DisplayPort™ and the DisplayPort™ logo are trademarks owned by the Video Electronics Standards Association (VESA®) in the United States and other countries. McAfee and McAfee LiveSafe are trademarks or registered trademarks of McAfee LLC in the United States and other countries. ENERGY STAR is a registered trademark of the U.S. Environmental Protection Agency. All other trademarks are the property of their respective owners. |
| Segment | Business |
| Usage | Performance computing |
| Legal tagline | HP recommends Windows 11 Pro for business |
| Overview | Be ready when inspiration strikes. Packed with professional performance in an incredibly sleek PC that comfortably fits in your bag, the ZBook Studio is engineered to get you in the zone and help you stay focused. Now you can build complex assemblies, render in real time or visualize data—from anywhere. |
| Company | HPI |
| Code name | Medusa |
| Product long name | HP Renew ZBook Studio (16) 40.64 cm G10 Mobile Workstation PC |
| Product short name specifications | HP ZBook Studio (16) 40.64 cm G10 Mobile Workstation PC, Intel® Core™ i7, 32GB RAM, 512GB SSD |
| Security management | Absolute persistence module; HP Credential Manager; HP Power On Authentication; Master Boot Record security; Pre-boot authentication; Windows Defender; HP Manageability Integration Kit; HP BIOSphere Gen6; HP Sure Start Gen6; HP Sure Admin; HP Image Assistant; Nano Security Lock Slot; HP Image Assistant Gen4.6; HP Client Security Manager Gen7; Trusted Platform Module TPM 2.0; HP Privacy Key |
| Management features | HP Power Manager |
| Product classification flag | Refurbished/Remarketed |
| Tangible flag | Y |
| Material Type for item | FERT |
Notes and footnotes
- A product carbon footprint is defined as the total amount of greenhouse gases emitted directly and indirectly by a product over its lifetime. Greenhouse gas emissions are reported as global warming potential for 100-year time horizon (GWP-100) in units of CO2 equivalence. Calculations are done in accordance with ISO 14040 & ISO 14044. Individual values may not sum to total due to rounding.
- [1] Multicore is designed to improve performance of certain software products. Not all customers or software applications will necessarily benefit from use of this technology. Performance and clock frequency will vary depending on application workload and your hardware and software configurations. Intel’s numbering, branding and/or naming is not a measurement of higher performance.
- [2] Optional feature that must be configured at purchase.
- [5] AI Noise Reduction is delivered automatically through Windows update or can be downloaded from https://support.hp.com/us-en/drivers when available. Requires Windows 10 or higher, compatible with internal PC speakers, microphone and analog headsets. The DNN Noise Reduction setting can be configured through the Application HP Audio Control.
- [2] This system is preinstalled with Windows 10 Pro software and also comes with a license for Windows 11 Pro software and provision for recovery software. You may only use one version of the Windows software at a time. Switching between versions will require you to uninstall one version and install the other version. You must back up all data (files, photos, etc.) before uninstalling and installing operating systems to avoid loss of your data.
- [3] Processor speed denotes maximum performance mode; processors will run at lower speeds in battery optimization mode.
- [7] Z Light Space requires Windows 10 or higher.
- [4] Intel® Turbo Boost performance varies depending on hardware, software and overall system configuration. See http://www.intel.com/technology/turboboost for more information.
- [8] RGB keyboard is an optional, configurable feature. Available only in the US, UK, Germany and France only.
- [5] In accordance with Microsoft’s support policy, HP does not support the Windows 8 or Windows 7 operating system on products configured with Intel and AMD 7th generation and forward processors or provide any Windows 8 or Windows 7 drivers on http://www.support.hp.com .
- [9] MIL STD testing is not intended to demonstrate fitness for U.S. Department of Defense contract requirements or for military use. Test results are not a guarantee of future performance under these test conditions. Accidental Damage or damage under these test conditions requires an optional HP Accidental Damage Protection Care Pack.
- [6] Multi-core is designed to improve performance of certain software products. Not all customers or software applications will necessarily benefit from use of this technology. Performance and clock frequency will vary depending on application workload and your hardware and software configurations. Intel’s numbering, branding and/or naming is not a measurement of higher performance.
- [10] HP Wolf Security for Business requires Windows 10 or higher, includes various HP security features and is available on HP Pro, Elite, RPOS and Workstation products. See product details for included security features and OS requirement.
- [7] Intel® Turbo Boost performance varies depending on hardware, software and overall system configuration. See http://www.intel.com/technology/turboboost/ for more information.
- [22] Memory is an optional, configurable feature.
- [8] HP Tamper Lock is an optional feature that must be configured at the factory and requires a supervisor password be established prior to use.
- [9] Multicore is designed to improve performance of certain software products. Not all customers or software applications will necessarily benefit from use of this technology. Performance and clock frequency will vary depending on application workload and your hardware and software configurations. Intel’s numbering, branding and/or naming is not a measurement of higher performance.
- [10] For storage drives, GB = 1 billion bytes. TB = 1 trillion bytes. Actual formatted capacity is less. Up to 35GB (for Windows) is reserved for system recovery software.
- [11] Due to the non-industry standard nature of some third-party memory modules, we recommend HP branded memory to ensure compatibility. If you mix memory speeds, the system will perform at the lower memory speed.
- [12] Multi-Function USB-C port works with Discrete Graphics and Intel(r) Iris Xe Graphics. Note: For Nvidia Discreate Gfx, it can support HDMI 2.1 except GPU of QN20-P1 SKU(HDMI2.0 support).
- [13] Manage and monitor your battery’s performance and condition and customize charging options with the easy-to-use HP Power Manager dashboard.
- [14] Wi-Fi 6E requires a Wi-Fi 6E router, sold separately, to function in the 6GHz band. Availability of public wireless access points limited. Wi-Fi 6E is backwards compatible with prior 802.11 specs. And available in countries where Wi-Fi 6E is supported.
- [15] UHD content required to view UHD images.
- [16] HD content required to view HD images.
- [17] Windows Hello face authentication utilizes a camera specially configured for near infrared (IR) imaging to authenticate and unlock Windows devices as well as unlock your Microsoft Passport.
- [18] Both UMA and Discrete configurations support 4 independent displays (both Intel and NVIDIA Graphic cards, UMA/DIS mode need to close lid or only 3 displays max are supported externally. Max. resolution = 8K@60Hz (miniDP) 4K@60Hz (Type-C output port using a Type C-to-DP adapter), 4K@60Hz (Type-C output port using a Type C-to-DP adapter), OR 4K @60Hz (DP1) & 2.5K @60Hz (DP2) & FHD (VGA) OR 4K @60Hz (one DP Port) & 4K @60Hz (Type-C output port using a Type C-to-DP adapter).
- [19] HP Smart Support automatically collects the telemetry necessary upon initial boot of the product to deliver device-level configuration data and health insights and is available preinstalled on select products, thru HP Factory Configuration Services; or it can be downloaded. For more information about how to enable HP Smart Support or for download, please visit http://www.hp.com/smart-support .
- [20] Shared video memory (UMA) uses part of the total system memory for video performance. System memory dedicated to video performance is not available for other use by other programs.
- [21] HP Services Scan is provided with Windows Update on select products and will check entitlement on each hardware device to determine if an HP TechPulse-enabled service has been purchased, and will download applicable software automatically. HP TechPulse is a telemetry and analytics platform that provides critical data around devices and applications. For full system requirements or to disable this feature, please visit http://www.hpdaas.com/requirements . Not applicable in China.
- [22] GPU configurations may be limited to specific GPU/Memory Configurations
- [24] HP RGB Z Command Keyboard only available in the US, UK, France, and Germany. Not available with Privacy Panel.
- [25] Data Science Stack is available on select skus only.
- [26] For new batteries, actual battery Watt-hours (Wh) may differ from the design capacity and may have a full charge capacity that differs by up to 10, which is typical for lithium-ion batteries. Battery capacity naturally decreases over time and with use, depending on several factors such as battery health management settings, shelf life, temperature, environment, loaded apps, features, system configuration, and power settings.
- [27] Display options may be limited to specific CPU / GPU Configurations.
- [28] HP Z Light space is an optional feature, requires Windows 10 or higher and must be configured at hardware purchase.
- [29] Resolutions are dependent upon monitor capability, and resolution and color depth settings.
- [30] Available on select HP PCs with Windows 10 and higher and Intel processors.
- [31] Miracast is a wireless technology your PC can use to project your screen to TVs, projectors, and streaming media players that also support Miracast. You can use Miracast to share what you’re doing on your PC and present a slide show. For more information: http://windows.microsoft.com/en-us/windows-8/project-wireless-screen-miracast .
- [32] Others NVIDIA dGPU: Support HD decode, DX12, HDMI 2.1, mDP 1.4, HDCP 2.3 via DP up to 5K@60Hz(W/o DSC) or 8K@60(With DSC and requires 2 display heads) and via HDMI up to 8K @ 60Hz(With DSC and requires 2 display heads)
- [33] HP Connection Optimizer requires Windows 10.
- [34] HP BIOSphere Gen6 features may vary depending on the platform and configuration.
- [35] Absolute agent is shipped turned off, and will be activated when customers activate a purchased subscription. Subscriptions can be purchased for terms ranging multiple years. Service is limited, check with Absolute for availability outside the U.S. The Absolute Recovery Guarantee is a limited warranty. Certain conditions apply. For full details visit: http://www.absolute.com/company/legal/agreements/computrace-agreement . Data Delete is an optional service provided by Absolute Software. If utilized, the Recovery Guarantee is null and void. In order to use the Data Delete service, customers must first sign a Pre-Authorization Agreement and either obtain a PIN or purchase one or more RSA SecurID tokens from Absolute Software.
- [37] HP Manageability Integration Kit can be downloaded from http://www.hp.com/go/clientmanagement .
- [38] Security lock for security slot is sold separately.
- [39] HP Client Security Manager Gen7 requires Windows and is available on the select HP Elite and Pro PCs.
- [43] HP Sure Start Gen6 is available on select HP PCs.
- [45] Based on US EPEAT® registration according to IEEE 1680.1-2018 EPEAT®. EPEAT® status varies by country. Visit www.epeat.net for more information.
- [46] External power supplies, power cords, cables and peripherals are not low halogen. Service parts obtained after purchase may not be low halogen.
- [47] HP Fact Charge recharges up to 50% within 30 minutes when the system is off or in standby mode. Power adapter with a minimum capacity of 65 watts is required. After charging has reached 50% capacity, charging will return to normal. Charging time may vary +/-10% due to System tolerance.
- [48] 150W Power Adapter is not available with Nvidia RTX™ Graphics
- [49] HP Sure Admin requires Windows 10 or higher, HP BIOS, HP Manageability Integration Kit from http://www.hp.com/go/clientmanagement and HP Sure Admin Local Access Authenticator smartphone app from the Android or Apple store.
- [51] HP Easy Clean requires Windows 10 RS3 and will disable the keyboard, touchscreen, and clickpad only. Ports are not disabled. See user guide for clean.
- [52] Select HP Products are enhanced with HP Presence. Features vary by platform. HP conferencing features require Windows and the latest myHP app, available over the air or for download via sofpaq on the HP Support website. Planned availability in spring 2023.
- [59] MicroSD 7.1 media reader supports SD 4.0 cards at SD 3.0 speeds with any SD 7.0 host. SD 7.0 card availability is expected later in 2022.
- [60] Depending on the version available for your device and the setting you select, HP Battery Health Manager (BHM) will use a proprietary set of algorithms to optimize battery health during the life of the battery. New Commercial Notebooks come equipped with BHM set to “Let HP Manage My Battery Health” as the default. This setting will reduce charge capacity over time to optimize battery health and mitigate factors that can accelerate battery degradation. As a result of this reduction, battery runtime will decrease over time as available charge capacity is reduced. HP may, at any time, update HP Battery Health Manger to improve available settings, functionality, and performance. Refurbished products may have customized default settings to optimize user experience. For additional information on updating or modifying HP Battery Health Manager settings, please go to HP.COM/SUPPORT/BATTERY.
