| What's in the box |
HP Engage One Pro Fingerprint Reader; Documentation; Warranty card |
| Registration required |
No |
| Compatibility |
Compatible with HP Engage One Pro All-in-One system. |
| Country of origin |
China |
| Headline |
Integrated, space-saving design |
| Key selling point |
Reduce opportunities for theft, while enabling fast, secure, and highly accurate employee log-in for the HP Engage One Pro. Always active finger detection reads prints whether the unit is active, in stand by, or even deep sleep mode.[1] |
| Image legal disclaimer |
Product image may differ from actual product |
| Overview |
Speed up and simplify the employee log-in process, while ensuring maximum accuracy and security. Our fingerprint reader integrates seamlessly into the HP Engage One Pro for easy and effective checkout security. |
| Company |
HPI |
| Product long name |
HP Engage One Pro Fingerprint Reader |
| Product classification flag |
Standard HP Product |
| Technical notes |
Sensor Type: Capacitive; Array Size: 208 x 288 pixels; Image Resolution: 508 DPI; Gray Scale: 8-bit (256 levels); Image Area: 10.4 x 14.4 mm; Image/Coating: Steel Coat; NVM Storage: 100 templates; Data Retention: 20 years; Erase/Write: 100,000 cycles; Connection Interface: USB 2.0; Interface Connector: 5 pin, 0.8mm pitch wire-type (gold-plated); Operating temperature: -30° to +85°C; Storage Temperature: -40? C to +85? C; Humidity (non-condensing): 5% to 85%; ESD Tolerance: IEC 61000-4-2 Level 4; Power Supply: 3.0V to 3.6V; Imaging mode: 105 mA @ 3.3V; Sleep mode: 1350 uA @ 3.3V Wake-up Time: < 15 ms (Sleep to imaging); Drivers: Windows USB HID-KB and OPOS & JPOS (via USB-COM mode drivers); Color: HP Black |
| Tangible flag |
Y |
| Material Type for item |
FERT |
