Key features
- Adjustable stand
- Integrated speakers
- VESA mountable
- Sustainable
- HP Eye Ease
- WWCB Certified
- IPS panel
- IPS Technology
- 100 Hz Refresh Rate
- Height and Tilt Adjust
- Plenty of Ports
- 3-Sided Micro-Edge Bezel
Technical specifications
Product
| UPC number | 198828035646 |
|---|---|
| Product type | Monitors |
Storage
| Storage altitude | Up to 40,000 ft |
|---|
Display
| Aspect ratio | 16:9 |
|---|---|
| Backlight lamp life minimum (to half brightness) | 30,000 hours |
| Brightness | 250 nits |
| Bezel | 3-sided borderless |
| Display area (metric) | 52.7 x 29.65 cm |
| Display colors | Up to 16.7 million colors supported |
| Display contrast ratio (dynamic) | 8000000:1 |
| Display features | Height adjustable; Tilt |
| Display size (diagonal) | 60.5 cm (23.8") |
| Flicker-free | Yes (TÜV certified) |
| Onscreen controls | Brightness+; Color; Image; Input; Power; Menu; Management; Information; Exit |
| Native resolution | FHD (1920 x 1080) |
| Panel bit depth | 8 bit (6 bit + FRC) |
| Panel technology | IPS; LCD |
| Resolution (maximum) | FHD (1920 x 1080 @ 100 Hz) |
| Resolutions supported | 640 x 480 @ 60 Hz; 720 x 400 @ 70 Hz; 800 x 600 @ 60 Hz; 1024 x 768 @ 60 Hz; 1280 x 720 @ 60 Hz; 1280 x 1024 @ 60 Hz; 1440 x 900 @ 60 Hz; 1600 x 900 @ 60 Hz; 1680 x 1050 @ 60 Hz; 1920 x 1080 @ 60 Hz; 640 x 480 @ 75 Hz (digital inputs only); 800 x 600 @ 75 Hz (digital inputs only); 1024 x 768 @ 75 Hz (digital inputs only); 1280 x 1024 @ 75 Hz (digital inputs only); 1920 x 1080 @ 50 Hz (digital inputs only); 1920 x 1080 @ 75 Hz (digital inputs only); 1920 x 1080 @ 100 Hz (digital inputs only); 1280 x 800 @ 60 Hz |
| Screen treatment | Anti-glare |
| Maximum resolution | 1920 x 1080 (FHD) |
| Resolution | FHD |
| Screen size (cm) | 60.5 |
| Screen size range | 23 - 25 |
| Screen size (in) | 23.8 |
Camera and audio
| Camera | No integrated camera |
|---|
Ports
| Ports | HDMI; VGA; DisplayPort |
|---|---|
| DisplayPort™ | 1 DisplayPort™ 1.2 |
| HDMI | 1 HDMI 1.4 |
| VGA | 1 VGA |
Battery and power
| Power supply type | Internal |
|---|
Software
| Management Software | HP Display Center; HP Client Management Script Library |
|---|
Copy and scan
| Display scan frequency (horizontal) | 30-115 kHz |
|---|---|
| Display scan frequency (vertical) | 48-100 Hz |
Physical
| Product color | Black |
|---|---|
| Dimensions (W x D x H) | 21.22 x 1.94 x 12.76 in (without stand) |
| Product dimensions with stand (W x D x H) | 21.22 x 7.73 x 18.47 in |
| Dimensions With Stand (W x D x H) | 53.89 x 19.63 x 46.92 cm |
| Color gamut | 72% NTSC |
Package
| Package dimensions (W x D x H) | 23.43 x 4.88 x 15.39 in |
|---|---|
| Pallet dimensions | Slip sheet: 47.24 x 39.45 x 77.95 in (20 ft, 40 ft); Slip sheet: 47.24 x 39.45 x 93.46 in (40 ft HQ); Pallet: 47.24 x 39.45 x 82.68 inch (20 ft, 40 ft); Pallet: 47.24 x 39.45 x 98.19 in (40 ft HQ) |
| Pallet dimensions (W x D x H) | Slip sheet: 120 x 100.2 x 198 cm (20 ft, 40 ft); Slip sheet: 120 x 100.2 x 237.4 cm (40 ft HQ); Pallet: 120 x 100.2 x 210 cm (20 ft, 40 ft); Pallet: 120 x 100.2 x 249.4 cm (40 ft HQ) |
Sustainability
| Energy star certified | ENERGY STAR® certified |
|---|---|
| Environmental certification | ENERGY STAR® certified; EPEAT® registered; TCO Certified; TCO Certified Edge |
| EPEAT registered | EPEAT registered with Climate+ |
| Sustainability specifications | At least 85% post-consumer recycled plastic; At least 5% recycled metal; Contains 20% recycled glass in the monitor panel; Molded paper pulp cushion inside box is made of 100% recycled or certified sources; Low halogen |
| Energy Usage CO2e (kg) | 161.626 |
| End of Life CO2e (kg) | 1.502 |
| Production CO2e (kg) | 87.776 |
| Total CO2e (kg) | 252.313 |
| Transportation CO2e (kg) | 1.409 |
Warranty and service
| Manufacturer Warranty | HP three-year limited warranty |
|---|
Other
| What's in the box | Monitor; HDMI cable; Warranty card; Quick Setup Poster; AC power cord |
|---|---|
| Power consumption | 35 W (maximum), 23 W (typical), 0.5 W (standby) |
| Power | 100 - 240 VAC 50/60 Hz |
| Registration required | No |
| Brand | HP |
| Series name | HP Series 3 Pro 23.8 inch |
| Sub brand | HP Series 3 Pro |
| Certifications and compliances | Australia MEPS; Bauart; CCC; CE; CEL; C-Tick; cTUVus; EAC; E-standby (Korea); EUP Lot-5; EUP Lot-6; FCC; ISO 9241-307; KC (Korean) requirements; KCC (Korean) requirements; NOM (Mexico); PSB for Singapore; RCM; SEPA; S-Mark for Argentina; Taiwan BSMI; VCCI; Vietnam MEPS; Ukraine Energy label; California Energy Commission (CEC); South Africa Energy; EUP Lot 26; Mexico Energy; UAE; TGM; India BIS; Cambodia ISC; IC; NRCS; PSE; Ukraine CoC; Ukraine DOC; CEL Grade 2; CB(62368-1); CB 60950 |
| TCO Certified | TCO Certified, generation 10; TCO Certified, Edge |
| HDCP | Yes, DisplayPort™ and HDMI |
| Video connectors | HDMI; DisplayPort™-in |
| Base area footprint (metric) | 18.5 x 17.8 cm |
| Backlight type | Edge-lit; WLED |
| Curvature | Flat |
| Detachable stand | Yes |
| Contrast ratio | 1000:1 |
| Hardness | 3H |
| Haze | 25% |
| Horizontal viewing angle | 178° |
| Low blue light | HP Eye Ease (TÜV Low Blue Light Hardware Solution certified) |
| Pixel pitch | 0.2745 x 0.2745 mm |
| Pixels per inch (ppi) | 93 ppi |
| Refresh rate (maximum) | 100 Hz |
| Response time (typical) | 5ms GtG (with overdrive) |
| Stand type | Base stand; With stand; Height adjustable stand |
| Tilt | -5 to +23° |
| VESA mounting | 100 x 100 mm |
| Viewable diagonal size | 23.8" (60.45 cm) |
| Non-Operating Humidity Range | 5 – 95% |
| Non-operating temperature - Celsius | -40 to 65°C |
| Non-operating temperature - fahrenheit | -40 to 149°F |
| Operating altitude | Up to 16,400 ft |
| Operating humidity range | 20 to 80% RH (non-condensing) |
| Operating temperature range | 41 to 95°F |
| Country of origin | China(AB0, AC8, ABA, AB1, AB4, ACJ, UUF, A2K, AB2, AKH, AR6, AKL); Thailand(ABB, UUZ, ACQ, AB0, AC8, A2N, ABJ, ABG, ABA, ABT, ABY, ABU, ABV, AB1, AH3, AB4, ACJ, UUF, A2K, AKH, AC4, AR6, AKL) |
| Headline | Elevate your visual experience |
Notes and footnotes
- A product carbon footprint is defined as the total amount of greenhouse gases emitted directly and indirectly by a product over its lifetime. Greenhouse gas emissions are reported as global warming potential for 100-year time horizon (GWP-100) in units of CO2 equivalence. Calculations are done in accordance with ISO 14040 & ISO 14044. Individual values may not sum to total due to rounding.
- [1] All performance specifications represent the typical specifications provided by HP's component manufacturers; actual performance may vary either higher or lower. 100 Hz refresh rate can be supported via HDMI and DisplayPort™ cable connection only. 60 Hz refresh rate with VGA.
- [2] Recycled plastic content percentage is based on the definition set in the IEEE 1680.1-2018 EPEAT® standard. Recycled plastic is expressed as a percentage of the total weight plastic. Recycled metal is expressed as a percentage of the total weight of the metal according to ISO 14021 definitions for metal parts over 25 grams. Percentage of recycled glass in the monitor panel varies by product. Recycled glass is expressed as a percentage of the total weight of the glass.
- [3] Based on US EPEAT® registration according to IEEE 1680.1-2018 EPEAT®. EPEAT® status varies by country. Visit www.epeat.net for more information.
- [1] All specifications represent the typical specifications provided by HP's component manufacturers, actual performance may vary either higher or lower.
- [2] DisplayPort™ 1.2 or HDMI 1.4 required to drive panel at its native resolution. The video card of the connected PC must be capable of supporting 1920 x 1080 at 60 Hz with 8-bit color using one HDMI, DisplayPort™ or VGA.
- [3] Number of colors through A-FRC technology.
- [4] Included cables may vary by country.
- [5] Lock sold separately.
- [6] ITE Derived Closed Loop Plastic percentage is based on the definition set in the IEEE 1680.1-2018 standard.
- [7] Recycled metal is expressed as a percentage of the total weight of the metal according to ISO 14021 definitions for metal parts over 25 grams.
- [8] Percentage of recycled glass in the monitor panel varies by product. Recycled glass is expressed as a percentage of the total weight of the glass.
- [9] HP paper and fiber based packaging for PCs, displays, home and office print, and supplies is reported by suppliers as recycled or certified, with a minimum of 97% by volume verified by HP. Packaging is the box that comes with the product and all paper-based materials inside the box. Packaging for personal systems accessories and spare parts is not included.
- [10] External power supplies, WWAN modules, power cords, cables and peripherals excluded. Service parts obtained after purchase may not be Low Halogen.
- [11] Host PC requires Windows 10. HP Display Center is available on the Microsoft store.
- [12] HP CMSL is estimated to be available between November 2024 to April 2025. HP CMSL is only supported on 64-bit PowerShell 5.1 and higher. CMSL Support Windows 10 version 1809 and higher, and Windows 11. Some limitations may apply to legacy displays. Visit support.hp.com to download HP CMSL.
- [13] Not all features are available in all editions or versions of Windows. Systems may require upgraded and/or separately purchased hardware, drivers, software or BIOS update to take full advantage of Windows functionality. Windows is automatically updated and enabled. High speed internet and Microsoft account required. ISP fees may apply and additional requirements may apply over time for updates. See http://www.windows.com.
- [15] TCO Certified is a ISO 14024 Type 1 sustainability label for IT products. Compliance with all criteria is independently verified.
