SKU: B88JWAA
HP Series 5 Pro 14 inch WQXGA Portable Monitor - 514pn
Contact us for pricing
Key features
- Portable
- USB Type-C® Power Delivery
- HP Eye Ease
- Seamless Color Consistency Without Compromise
- Deeper Blacks, Vibrant Whites
- WQXGA Resolution
- See Your Work in Any Light
- 75 Hz Refresh Rate
- Progressive White Balance
- Stay Connected with a Single Cable
- Thin, Light Design with Hard Cover Protection
- A Versatile Stand that Supports Flexibility
Technical specifications
Product
| UPC number | 198990467924 |
|---|---|
| Product type | Monitors |
Storage
| Storage altitude | Up to 40,000 ft |
|---|
Display
| Aspect ratio | 16:10 |
|---|---|
| Backlight lamp life minimum (to half brightness) | 15,000 hours |
| Brightness | 400 nits |
| Bezel | Narrow |
| Display area (metric) | 30.15 x 18.84 cm |
| Display colors | Up to 16.7 million colors supported |
| Display contrast ratio (dynamic) | 10,000,000:1 |
| Display features | Tilt |
| Display size (diagonal) | 36.5 cm (14.36") |
| Flicker-free | Yes (TÜV certified) |
| Onscreen controls | Brightness+; Color |
| Native resolution | WQXGA (2560 x 1600) |
| Panel bit depth | 8 bit |
| Panel technology | IPS Black; Neo:LED |
| Resolution (maximum) | WQXGA (2560 x 1600 @ 75 Hz) |
| Resolutions supported | 640 x 480 @ 60 Hz; 640 x 480 @ 75 Hz; 720 x 400 @ 70 Hz; 800 x 600 @ 60 Hz; 800 x 600 @ 75 Hz; 1024 x 768 @ 60 Hz; 1280 x 720 @ 60 Hz; 1280 x 1024 @ 60 Hz; 1440 x 900 @ 60 Hz; 1600 x 900 @ 60 Hz; 1600 x 1200 @ 60 Hz; 1680 x 1050 @ 60 Hz; 1920 x 1080 @ 60 Hz; 1920 x 1200 @ 60 Hz; 1280 x 1024 @ 75 Hz; 2560 x 1600 @ 60 Hz; 1024 x 768 @ 75 Hz; 2560 x 1600 @ 75 Hz |
| Screen treatment | Anti-glare |
| Maximum resolution | 2560 x 1600 (WQXGA) |
| Resolution | WQXGA |
| Screen size (cm) | 35.6 |
| Screen size range | < 22 |
| Screen size (in) | 14 |
Camera and audio
| Camera | No integrated camera |
|---|
Ports
| Ports | USB-C |
|---|---|
| USB Type-C® video input | 2 USB Type-C® (up to 65W USB Power Delivery, Alt Mode DisplayPort™ 1.2) |
Battery and power
| Power supply type | External |
|---|
Software
| Management Software | HP Display Center; HP Client Management Script Library |
|---|
Copy and scan
| Display scan frequency (horizontal) | 31-124 kHz |
|---|---|
| Display scan frequency (vertical) | 50-75 Hz |
Physical
| Product color | Silver |
|---|---|
| Product dimensions with stand (W x D x H) | 12.62 x 0.35 x 8.21 in |
| Dimensions With Stand (W x D x H) | 32.06 x 0.88 x 20.86 cm |
| Color gamut | 100% Display P3; 100% Adobe RGB |
Package
| Package dimensions (W x D x H) | 15.67 x 2.36 x 10.94 in |
|---|---|
| Pallet dimensions | Slip sheet: 39.37 x 47.24 x 83 in (20 ft, 40 ft); 39.37 x 47.24 x 94.81 in (40 HQ); Pallet: 39.37 x 47.24 x 76.42 in (20 ft, 40 ft); 39.37 x 47.24 x 88.23 in (40 HQ) |
| Pallet dimensions (W x D x H) | Slip sheet: 100 x 120 x 210.8 cm (20 ft, 40 ft); 100 x 120 x 240.8 cm (40 HQ); Pallet: 100 x 120 x 194.1 cm (20 ft, 40 ft); 100 x 120 x 224.1 cm (40 HQ) |
Sustainability
| Ecolabels | Taiwan Green Mark; Japan PC Green Label |
|---|---|
| Energy star certified | ENERGY STAR® certified |
| Environmental certification | ENERGY STAR® certified; EPEAT® registered; Low halogen; Recycled Material |
| EPEAT registered | EPEAT registered with Climate+ |
| Sustainability specifications | At least 55% recycled aluminum; Contains ocean-bound plastic; Contains 20% recycled glass in the monitor panel; Molded paper pulp cushion inside box is made of 100% recycled or certified sources; Outside box and corrugated cushions are 100% from certified or recycled sources and recyclable; At least 90% post-consumer recycled plastic; Low halogen |
| Energy Usage CO2e (kg) | 65.077 |
| End of Life CO2e (kg) | 0.561 |
| Production CO2e (kg) | 66.456 |
| Total CO2e (kg) | 132.671 |
| Transportation CO2e (kg) | 0.577 |
Warranty and service
| Manufacturer Warranty | HP three-year limited warranty |
|---|
Other
| What's in the box | Monitor; Warranty card; Quick Setup Poster; 1 USB Type-C® to Type-C cable; Hard screen cover |
|---|---|
| Power consumption | 13 W (maximum); 7 W (typical) |
| Power | USB Type-C® input : DC 5V or 9V or 10V or 12V or 15V or 20V, 4.5A MAX; USB Type-C® output: DC 5V or 9V or 12V or 15V, 3A MAX or 20V, 3.25A MAX |
| Standby mode power demand | 0.5 W |
| Registration required | No |
| Brand | HP |
| Series name | HP Series 5 Pro 14 inch |
| Sub brand | HP Series 5 Pro |
| Certifications and compliances | BIS; BSMI; CB; CCC; CE; cTUVus; EAC; FCC; ISO 9241-307; KC; KCC; NOM; TUV/GS; VCCI; Vietnam MEPS; WEEE; ISC; ICE; UAE; NRCS |
| Energy efficiency class | B |
| HDCP | Yes, USB Type-C® |
| Video connectors | USB Type-C® |
| Backlight type | Edge-lit |
| Curvature | Flat |
| Contrast ratio | 2000:1 |
| Hardness | 3H |
| Haze | 25% |
| Horizontal viewing angle | 178° |
| Low blue light | HP Eye Ease (TÜV Low Blue Light Hardware Solution certified) |
| Pixel pitch | 0.1178 x 0.1178 mm |
| Pixels per inch (ppi) | 216 ppi |
| Refresh rate (maximum) | 75 Hz |
| Response time (typical) | 7ms GtG (with overdrive) |
| Stand type | With stand |
| Tilt | +18.8 to +46.2° |
| Viewable diagonal size | 14" (35.56 cm) |
| Non-Operating Humidity Range | 5 - 95% |
| Non-operating temperature - Celsius | -40 to 65°C |
| Non-operating temperature - fahrenheit | -40 to 149°F |
| On mode power demand in Standard Dynamic Range (SDR) | 5.6 W |
| Operating altitude | Up to 16,400 ft |
| Operating humidity range | 20 to 80% RH (non-condensing) |
| Operating temperature range | 41 to 95°F |
Notes and footnotes
- A product carbon footprint is defined as the total amount of greenhouse gases emitted directly and indirectly by a product over its lifetime. Greenhouse gas emissions are reported as global warming potential for 100-year time horizon (GWP-100) in units of CO2 equivalence. Calculations are done in accordance with ISO 14040 & ISO 14044. Individual values may not sum to total due to rounding.
- [1] Cable included. 5v@3A from the connected device required for power to the display. Video over USB-C™ requires a device with USB-C™ DisplayPort™ Alt mode or Thunderbolt™ 3.
- [2] All performance specifications represent the typical specifications provided by HP's component manufacturers; actual performance may vary, either higher or lower.
- [3] Recycled plastic is expressed as a percentage of the total weight plastic. Post-consumer recycled is based on the definition set in the EPEAT criteria. Percentage of recycled glass in the monitor panel varies by product. Recycled glass is expressed as a percentage of the total weight of the glass. Recycled metal is expressed as a percentage of the total weight of the metal according to ISO 14021 definitions for metal parts over 25 grams.
- [1] All performance specifications represent the typical specifications provided by HP's component manufacturers; actual performance may vary, either higher or lower.
- [4] HP paper and fiber based packaging for PCs, displays, home and office print, and supplies is reported by suppliers as recycled or certified, with a minimum of 97% by volume verified by HP. Packaging is the box that comes with the product and all paper-based materials inside the box. Packaging for personal systems accessories and spare parts is not included.
- [10] Based on internal testing of HP Series 7 Pro and HP Series 5 Pro monitors with USB Type-C® or HDMI connections to devices on macOS and Windows, March 2024 and September 2024. Requires USB Type-C® or HDMI connectivity. Some features may not be supported.
- [2] DisplayPort™ 1.2 required to drive panel at its native resolution. The video card of the connected PC must be capable of supporting 2560 x 1600 at 60 Hz with 8-bit color using one USB Type-C® (DisplayPort™ alt mode). The video card of the connected PC must be capable of supporting 1920 x 1080 at 60 Hz and include 1 USB Type-C® (DisplayPort™ alt mode) outputs to drive the monitor at the Preferred Mode.
- [3] Included cables may vary by country.
- [4] Host PC requires Windows 10 or higher. HP Display Center is available for download on the Microsoft store for Windows or support.hp.com for Windows and MacOS.
- [5] The Client Management Script Library must be downloaded to the connected PC to run CMSL commands. Some limitations may apply to legacy displays. Visit hp.com to download HP CMSL.
- [6] EPEAT registered where applicable. EPEAT registration varies by country. See www.epeat.net for registration status by country. Based on US registration according to EPEAT criteria and EPEAT Climate+. Status and tier level varies by country. Visit www.epeat.net for more information.
- [7] Ocean Bound plastic is based on the definition set by the UL2809 standard.
- [8] Recycled metal is expressed as a percentage of the total weight metal as per defined in the EPEAT criteria.
- [9] Packaging parts contain certified or recycled fibers and are typically recycled in your local paper/carton recycling bin, consult your local guidelines.
- [10] Percentage of recycled glass in the monitor panel varies by product. Recycled glass is expressed as a percentage of the total weight of the glass.
- [11] Recycled plastic is expressed as a percentage of the total weight plastic. Post-consumer recycled is based on the definition set in the EPEAT criteria.
- [12] External power supplies, WWAN modules, power cords, cables and peripherals excluded. Service parts obtained after purchase may not be Low Halogen.
- [13] Not all features are available in all editions or versions of Windows. Systems may require upgraded and/or separately purchased hardware, drivers, software or BIOS update to take full advantage of Windows functionality. Windows is automatically updated and enabled. High speed internet and Microsoft account required. ISP fees may apply and additional requirements may apply over time for updates. See http://www.windows.com.
- [14] Maximum brightness and contrast setting with maximum power loading on USB downstream ports (for power consumption maximum); Factory default brightness and contrast setting with 25% power loading on USB downstream ports (for power consumption typical).
- [15] As defined in EU 2019/2021 and EU 2019/2013.
- [16] Please refer to the warranty card supplied with the product for details. Warranty may vary by country as required by law. Go to hp.com/support to learn about HP award winning service and support options in your region.
