Key features
- More Ports. More Flexibility.
- Compatible with myHP
- 3-year limited warranty
Technical specifications
Product
| UPC number | 199251520747 |
|---|---|
| Product type | Docking Stations |
| UNSPSC code | 43211602 |
Storage
| Storage altitude | -49.2 to 40,000 ft |
|---|
Display
| Displays supported | Triple monitor |
|---|---|
| Display support | Up to 3 external displays and 1 PC display or up to 3 external displays |
| Resolution (maximum) | Up to 4K |
| Resolutions supported | Multi-function PCs: 1 x 4K (3840 x 2160 @ 120 Hz)[1], 2 x QHD resolution (2560 x 1440 @ 120 Hz)[1], 3 x FHD (1920 x 1080 @ 120 Hz)[1]; High-resolution PCs with DisplayPort™ Alt Mode: 1 x 4K (3840 x 2160 @ 120 Hz)[1], 2 x 4K (3840 x 2160 @ 120 Hz)[1], 3 x 4K (3840 x 2160 @ 60 Hz)[1] |
Wireless
| Wireless technologies | WLAN Realtek RTL8721DM 802.11a/b/g/n; Bluetooth® |
|---|
Ports
| External I/O ports | USB Type-A; HDMI; DisplayPort; RJ-45; USB Type-C? power delivery |
|---|---|
| Ports | 2 USB Type-A 5Gbps signaling rate (charging); 1 HDMI 2.1; 2 DisplayPort™ 1.4; 1 RJ-45 (2.5 GbE); 1 USB Type-C® 10Gbps signaling rate (data and 15W USB Power Delivery) |
Software
| Certified collaboration software | DisplayPort™ |
|---|---|
| Compatible Operating Systems | Windows 11; Windows 10; macOS; Linux; ThinPro; ChromeOS |
| Software included | myHP |
Copy and scan
| Copyright notice | © Copyright 2026 HP Development Company, L.P. The information contained herein is subject to change without notice. The only warranties for HP products and services are set forth in the express warranty statements accompanying such products and services. Nothing herein should be construed as constituting an additional warranty. HP shall not be liable for technical or editorial errors or omissions contained herein. |
|---|
Physical
| Dimensions (W x D x H) | 12.1 x 12.1 x 5.1 cm |
|---|---|
| Weight | 1.49 lb |
Package
| Package dimensions (W x D x H) | 15.59 x 3.74 x 6.73 in |
|---|---|
| Pallet dimensions | 47.24 x 39.27 x 5.9 in |
| Pallet dimensions (W x D x H) | 120 x 100 x 15 cm |
| Package weight | 2.63 lb |
Sustainability
| Sustainability specifications | Plastic-free packaging; At least 35% post-consumer recycled plastic; Packaged in at least 35% recycled corrugated material |
|---|
Warranty and service
| Manufacturer Warranty | HP three-year limited warranty |
|---|
Other
| Cable length | 1 m |
|---|---|
| Connection type | USB Type-C® |
| What's in the box | HP USB-C 100W G6 Dock; 120 W power adapter; Product notice; Warranty card |
| Power delivery (PD) profiles | 12V/5A; 15V/5A; 20V/5A; 5V/3A; 9V/3A |
| Power to host | Up to 100 W via USB Type-C® (both HP and non-HP host devices) |
| Registration required | No |
| Brand | HP |
| Compatibility | Windows; macOS; ChromeOS?; Linux; ThinPro |
| Connector type | USB Type-C? |
| I/O Port location | Right side |
| Operating voltage | 19.5 V |
| Video connectors | HDMI; DisplayPort™-out |
| Refresh rate (maximum) | 120 Hz |
| Non-Operating Humidity Range | 5 to 95% non-condensing |
| Non-operating temperature - Celsius | -20 to 60°C |
| Non-operating temperature - fahrenheit | -4 to 140°F |
| Operating altitude | -49.2 to 10,000 ft |
| Operating humidity range | 10 to 90% non-condensing |
| Operating temperature range | 32 to 95°F |
| Country of origin | Made in China, Thailand and Mexico |
| Headline | Intuitive, compact design |
| Key selling point | Thoughtfully designed to fit any workspace. Stay in the know about device status updates with intuitive LED lighting and on-screen display notifications. This compact dock has a rear-facing USB-C® cable that frees your desk from wire clutter. |
| Key selling point for SEO | Thoughtfully designed for longevity and comes in plastic-free packaging[7] |
| Legal disclaimer | Actual product may vary from image shown. |
| Legal disclaimer [01] | [6] Comes with power cord. |
| Legal disclaimer [02] | [7] Requires Windows 10 or higher. |
| Legal disclaimer [03] | [8] HP includes a three-year limited warranty with online support available 24x7. Consult the HP Customer Support Center for details, or go to www.hp.com/go/orderdocuments. |
| Trademark information | USB Type-C® and USB-C® are registered trademarks of USB Implementers Forum. |
| Segment | Home |
| User type | Everyday; Office & Home work |
| Cable type | 1 back USB Type-C® cable to connect to host system (up to 100W USB Power Delivery) |
| Power button type | Mechanical power button with RGB LED indicator to power or wake host system |
| Overview | Say goodbye to cable chaos with your desk’s new best friend—the HP USB-C® 100W G6 Dock. One USB-C[1] cable links your laptop[2] up with all your gear. More ports, less fuss, and everything just works so you can stay in the zone. |
| Company | HPI |
| Code name | Abba |
| Product long name | HP USB-C 100W G6 Dock |
| Current, maximum | 6.15 A |
| Physical security | 1 nano security lock slot |
| Security management | HP Sure Start |
| Drivers included | Realtek NIC driver (ARM); Realtek NIC driver (Windows) |
| Product classification flag | Standard HP Product |
| Form factor | Dock |
| LED | Front LED bar: RGB LED (white, blue, amber, green, red); Power button: RGB LED (white, blue, amber, green, red) |
| Tangible flag | Y |
| Material Type for item | FERT |
Notes and footnotes
- [1] For USB-C® functionality, host PC must support the DisplayPort™ Alt mode protocol through its USB-C® port. Thunderbolt™-enabled notebooks will function at USB-C® speeds. Charging and port replication is supported on notebooks that have implemented USB-C® industry specifications. Power button to turn on or wake the system, on HP notebooks. HP does not provide Ethernet and audio drivers on Mac PCs".
- [2] Based on HP internal testing on select non-HP notebook models compatible with USB-C® industry standards. Certain Alt mode features are not supported, such as power button. Visit the HP Support page to determine your HP notebook's wattage and port specifications. Visit the support page of your non-HP notebook to determine its wattage and port specifications.
- [3] HP Total Test Process testing is not a guarantee of future performance under these test conditions. Damage under the HP Total Test Process test conditions or any accidental damage requires an optional HP Accidental Damage Protection Care Pack.
- [1] Requires DisplayPort™ 1.4 support with Display Stream Compression.
- [4] Replacements available through HP Customer Support Center. Consult the HP Customer Support Center for details, or go to www.hp.com/go/orderdocuments.
- [5] HP packaging for this product is reported by suppliers as plastic free. Packaging refers to the primary product box and all materials inside, excluding any additional boxes provided by third parties, bulk packaging, and packaging for accessories and spare parts.
- [2] Based on HP’s internal analysis of docking stations that have auto validating & self healing firmware, Meet NIST 800-173 requirements, the ability to disable the RJ-45 and a BIOS MAPT authorized list. HP Sure Start on HP Thunderbolt and USB-C® G6 dock supports firmware integrity verification and recovery during dock start-up and disconnect. It does not include real-time and runtime protections or Microsoft SCCM integration typically found on HP Sure Start in HP notebooks.
- [3] Operating systems supported: Windows 10 22H2 and up, Win 10 IoT Enterprise LTSC 2021, Windows 11 23H2 and up, ChromeOS M133 and up, Ubuntu Linux 22.04 LTS with 5.15 kernel, ThinPro OS 8.0 and MacOS Sonoma 14. Not all features work with all operating systems, ask your sales representative about compatibility with your PC. Linux, ChromeOS, MacOS, and ThinPro OS testing currently underway and expected to be completed after launch.
- [4] The dock power button may support non-HP notebooks that have implemented USB Power Delivery specification to support Extended Alert messages.
- [5] Please refer to the User Guide for LED light behaviors. The User Guide can be found on https://support.hp.com/.
- [6] Video resolution and support is dependent on the maximum capability of the notebook.
- [7] Compatible with the following HP locks: 63B28AA - HP Nano Combination Cable Lock, 63B31AA - HP Essential Nano Combination Cable Lock.
- [8] Recycled plastic content percentage is based on the definition set in the IEEE 1680.1-2018 standard.
- [9] HP packaging for this product is reported by suppliers as plastic free. Packaging refers to the primary product box and all materials inside, excluding any additional boxes provided by third parties, bulk packaging, and packaging for accessories and spare parts.
