SKU: C9406A
HP 70 Magenta and Yellow DesignJet Printhead
- Print technology
- Ink
Contact us for pricing
Technical specifications
Product
| UPC number | 882780756113 |
|---|---|
| UNSPSC code | 44103110 |
Display
| Product/Series display name | HP 70 Printheads |
|---|
| Print technology | HP Thermal Inkjet |
|---|---|
| Print Resolution Technologies | TIJ 4.0 |
| Printing Material Shelf Life | 18 months |
Copy and scan
| Copyright notice | © Copyright 2026 HP Development Company, L.P. The information contained herein is subject to change without notice. The only warranties for HP products and services are set forth in the express warranty statements accompanying such products and services. Nothing herein should be construed as constituting an additional warranty. HP shall not be liable for technical or editorial errors or omissions contained herein. |
|---|
Physical
| BCP bubble graphic color | Magenta and Yellow |
|---|---|
| Cartridge Colors | Magenta; Yellow |
| Dimensions (W x D x H) | 143 x 28 x 132 mm |
| Weight | 0.07 kg |
Package
| Larger master carton barcode | 10882780390772 |
|---|---|
| Pallet barcode | 20882780390779 |
| Package count | 1 |
| Case dimensions (case or master carton) | 14.4 x 11.7 x 5.9 in |
| Case or master carton dimensions (W x D x H) | 365 x 298 x 150 mm |
| European pallet dimensions (W x D x H) | 1219 x 1016 x 1325 mm |
| Package dimensions (W x D x H) | 28 x 143 x 132 mm |
| Larger master carton quantity | 24 |
| Quantity per pallet | 1920 |
| Larger master carton weight | 2.85 kg |
| Package weight | 0.1 kg |
| Pallet weight | 248 kg |
Sustainability
| Total CO2e (kg) | 3.9 |
|---|
Warranty and service
| Manufacturer Warranty | 9V - 6 Months Limited Warranty (Return to HP/Dealer) |
|---|---|
| Warranty | HP warrants that HP products are free from defects in workmanship or material under normal use in accordance with specifications until the date marked on the product. Warranty does not cover empty products or products that have been modified in any way. For complete warranty details contact your dealer or see www.hp.com/support/inkjet_warranty. You may also have statutory legal rights against the seller in addition to this manufacturer's warranty which are not restricted by this manufacturer's warranty. |
Other
| What's in the box | Printhead |
|---|---|
| Registration required | No |
| Selectability | 70 |
| Ink drop | 6 pl |
| Ink types | Pigment-based |
| Print head nozzles | 2112 |
| Printhead swath (inch) | 2.16 cm(0.85) |
| Supply type | Printheads |
| Compatibility | HP Designjet Z2100, Z3100 and Z3200 Photo Printer series |
| Non-Operating Humidity Range | 20 to 80% RH |
| Operating temperature range | 15 to 35° C |
| Why to buy | User-replaceable Original HP printheads are designed for problem-free performance. |
| Headline | You can count on Original HP printheads. Breakthrough HP printhead technology, designed to work with Original HP Photo Inks, delivers consistent print quality and color accuracy. Built-in intelligent technology maximizes printhead life. |
| Key selling point | Museum-quality photos and prints require precise detail, precise color. Original HP printheads feature an innovative printhead design with more nozzles, increasing ink drop accuracy so you get higher-quality prints. Designed together with Original HP Photo Inks, you get a wide color gamut and incredible detail. |
| Image legal disclaimer | Product image may differ from actual product |
| Product note | Brilliant, Enduring Colours |
| Stacking number for carton | 8 |
| Overview | Print museum-quality photos on virtually any media with long-life printheads. HP's breakthrough inkjet technology – with HP Vivera pigment inks – is ideal for professional photographers and ensures HP quality and reliability. |
| Photo (product photo, jpg, 190x170) | Ink Toner Paper Printer Supplies/C9406A_190x170.jpg |
| Photo (product photo, jpg, 400x400) | Ink Toner Paper Printer Supplies/C9406A_400x400.jpg |
| Photo (product photo, jpg, 70x100) | Ink Toner Paper Printer Supplies/C9406A_70x100.jpg |
| Company | HPI |
| Product long name | HP 70 Magenta and Yellow DesignJet Printhead |
| Short product name | HP 70 Magenta and Yellow Printhead |
| Product classification flag | Standard HP Product |
| Tangible flag | Y |
| Material Type for item | FERT |
Notes and footnotes
- A product carbon footprint is defined as the total amount of greenhouse gases emitted directly and indirectly by a product over its lifetime. Greenhouse gas emissions are reported as global warming potential for 100-year time horizon (GWP-100) in units of CO2 equivalence. Calculations are done in accordance with ISO 14040 & ISO 14044. Individual values may not sum to total due to rounding.
