SKU: D33DFUT
HP Series 5 Pro 27 inch FHD USB-C Docking Monitor 527fd G2
Contact us for pricing
Key features
- Adjustable stand
- VESA mountable
- USB Type-C® Power Delivery
- Docking
- Sustainable
- HP Eye Ease
- IPS panel
- FHD Resolution
- IPS Technology
- 120 Hz Refresh Rate
- More Contrast
- High Brightness
Technical specifications
Product
| UPC number | 199896436236 |
|---|---|
| Product type | Monitors |
Storage
| Storage altitude | Up to 40,000 ft |
|---|
Display
| Aspect ratio | 16:9 |
|---|---|
| Backlight lamp life minimum (to half brightness) | 30,000 hours |
| Brightness | 350 nits |
| Bezel | 3-sided borderless with micro-edge bezel |
| Display area (metric) | 59.79 x 33.63 cm |
| Display colors | Up to 16.7 million colors supported |
| Display contrast ratio (dynamic) | 10,000,000:1 |
| Display features | Height Adjust/Tilt/Swivel/Pivot |
| Display size (diagonal) | 68.6 cm (27") |
| Flicker-free | Yes (TÜV certified) |
| Onscreen controls | Brightness+; Color; Image; Input; Power; Menu; Management; Information; Exit |
| Native resolution | FHD (1920 x 1080) |
| Panel bit depth | 8 bit (6 bit + FRC) |
| Panel technology | IPS; LED |
| Resolution (maximum) | FHD (1920 x 1080 @ 120 Hz) |
| Resolutions supported | 640 x 480 @ 60 Hz; 640 x 480 @ 75 Hz; 720 x 400 @ 70 Hz; 800 x 600 @ 60 Hz; 800 x 600 @ 75 Hz; 1024 x 768 @ 60 Hz; 1024 x 768 @ 75 Hz; 1280 x 720 @ 60 Hz; 1280 x 800 @ 60 Hz; 1280 x 1024 @ 60 Hz; 1280 x 1024 @ 75 Hz; 1440 x 900 @ 60 Hz; 1600 x 900 @ 60 Hz; 1680 x 1050 @ 60 Hz; 1920 x 1080 @ 60 Hz; 1920 x 1080 @ 75 Hz; 1920 x 1080 @ 100 Hz; 1920 x 1080 @ 120 Hz |
| Screen treatment | Anti-glare |
| Maximum resolution | 1920 x 1080 (FHD) |
| Resolution | FHD |
| Screen size (cm) | 68.6 |
| Screen size range | 27 |
Camera and audio
| Camera | No integrated camera |
|---|
Ports
| Ports | HDMI; USB-C; USB port; USB hub; DisplayPort; DisplayPort out |
|---|---|
| DisplayPort™ | 1 DisplayPort™ 1.4 |
| DisplayPort™ Out | 1 DisplayPort™ 1.4-out |
| Ethernet | 1 RJ-45 (10/100/1000 Mbps) |
| HDMI | 1 HDMI 2.0 |
| USB Type-A | 3 USB Type-A 5Gbps signaling rate (1 charging) |
| USB Type-C® data | 1 USB Type-C® 5Gbps signaling rate (Up to 15W USB Power Delivery) |
| USB Type-C® video input | 1 USB Type-C® 5Gbps signaling rate (Up to 100W USB Power Delivery, Alt Mode DisplayPort™ 1.4) |
Battery and power
| Power supply type | Internal |
|---|
Software
| Management Software | HP Display Center; HP Client Management Script Library |
|---|
Copy and scan
| Display scan frequency (horizontal) | 30-150 kHz |
|---|---|
| Display scan frequency (vertical) | 50-120 Hz |
Physical
| Product color | Black |
|---|---|
| Stand color | Black; Silver |
| Dimensions (W x D x H) | 61.17 x 7.5 x 35.57 cm (without stand) |
| Product dimensions with stand (W x D x H) | 24.08 x 8.75 x 21.39 in |
| Dimensions With Stand (W x D x H) | 61.17 x 22.23 x 54.34 cm |
| Color gamut | 100% sRGB |
Package
| Package dimensions (W x D x H) | 27.32 x 6.06 x 17.56 in |
|---|---|
| Pallet dimensions | Slip sheet: 47.24 x 39.84 x 88.78 in (20 ft, 40 ft, 40 HQ) |
| Pallet dimensions (W x D x H) | Slip sheet: 120 x 101.2 x 225.5 cm (20 ft, 40 ft, 40 HQ) |
Sustainability
| Ecolabels | CECP; SEPA; Taiwan Green Mark; Japan PC Green Label; CEL Grade 2; Ukraine EE; Belarus EE; Korea MEPS; California CEC |
|---|---|
| Energy star certified | ENERGY STAR® certified |
| Environmental certification | ENERGY STAR® certified; EPEAT® registered; Low halogen; Recycled Material; TCO Certified; TCO Certified Edge; Sustainably sourced packaging |
| EPEAT registered | EPEAT Gold with Climate+ |
| Sustainability specifications | At least 90% post-consumer recycled plastic in the monitor’s enclosure; Contains ocean-bound plastic; At least 20% recycled metal including 90% recycled aluminum in the stand; Contains 20% recycled glass in the monitor panel; Molded paper pulp cushion inside box is made of 100% recycled or certified sources; Molded paper pulp cushion and folded corrugated cushion inside box are made of 100% recycled or certified sources; Outside box and corrugated cushions are made of 100% recycled or certified sources |
Warranty and service
| Manufacturer Warranty | HP three-year limited warranty |
|---|
Other
| What's in the box | Monitor; Warranty card; Quick Setup Poster; AC power cable (1.83 m); 1 USB Type-C® to Type-C® cable (PVC free) (1.8 m) |
|---|---|
| Power consumption | 200 W (maximum); 24 W (typical) |
| Power | 100 - 240 VAC 50/60 Hz |
| Standby mode power demand | 0.5 W |
| Registration required | No |
| Brand | HP |
| Series name | HP Series 5 Pro 27 inch |
| Sub brand | HP Series 5 Pro |
| Certifications and compliances | BIS; BSMI; CB; CCC; CE; CECP; cTUVus; EAC; FCC; ISO 9241-307; KC; KCC; NOM; PSB; RCM; SEPA; TUV-S; VCCI; WEEE; ISC; ICE; UAE; TUV-GS; ErP LOT5; Ukraine certificates; TÜV Flicker free certified; NRCS; Ukraine EE; TÜV Low Blue Light Hardware Solution certified; KMEPS; Australian-New Zealand DoC; EMF; Japan PSE |
| Energy efficiency class | C |
| TCO Certified | TCO Certified, generation 10; TCO Certified, Edge |
| HDCP | Yes, DisplayPort™, HDMI and USB Type-C® |
| Base area footprint (metric) | 25.6 x 20.7 cm |
| Backlight type | Edge-lit |
| Curvature | Flat |
| Detachable stand | Yes |
| Contrast ratio | 1500:1 |
| Hardness | 3H |
| Haze | 25% |
| Horizontal viewing angle | 178° |
| Low blue light | HP Eye Ease (TÜV Low Blue Light Hardware Solution certified) |
| pivot | ±90° |
| Pixel pitch | 0.3114 x 0.3114 mm |
| Pixels per inch (ppi) | 82 ppi |
| Refresh rate (maximum) | 120 Hz |
| Response time (typical) | 5ms GtG (with overdrive) |
| Stand type | With stand; Height adjustable stand |
| Swivel | ±45° |
| Tilt | -5 to +20° |
| VESA mounting | 100 x 100 mm |
| Viewable diagonal size | 27" (68.58 cm) |
| Non-Operating Humidity Range | 5 - 95% |
| Non-operating temperature - Celsius | -40 to 65°C |
| Non-operating temperature - fahrenheit | -40 to 149°F |
| On mode power demand in Standard Dynamic Range (SDR) | 14 W |
| Operating altitude | Up to 16,400 ft |
| Operating humidity range | 20 to 80% RH (non-condensing) |
| Operating temperature range | 41 to 95°F |
Notes and footnotes
- [1] Works across any OS. Keeps the same power delivery when connecting multiple devices.
- [2] All performance specifications represent the typical specifications provided by HP's component manufacturers; actual performance may vary, either higher or lower.
- [3] The HP Progressive White Balance feature is designed to calibrate 100% full white on HP Series 5 Pro monitors. This adjustment is intended to align the white point more closely among various HP Series 5 Pro monitors. However, due to the nature of monitors, perceptible differences in the white color may still occur when the monitors are viewed from varying angles.
- [1] All performance specifications represent the typical specifications provided by HP's component manufacturers; actual performance may vary, either higher or lower.
- [4] 120 Hz refresh rate supported on host PCs with DisplayPort™ 1.2 or higher. Host PC may affect the refresh rate combinations of monitors 1 and 2. Refresh rates can be user enabled in PC settings.
- [5] HP Series 5 Pro monitor or additional monitor sold separately.
- [2] DisplayPort™ 1.2 or HMDI 1.4 required to drive panel at its native resolution. The video card of the connected PC must be capable of supporting 1920 x 1080 @ 60 Hz with 8 bit color using one DisplayPort™, HDMI, or USB-C (DisplayPort™-Alt mode).
- [6] Ergonomic Setup Guide is available through HP Display Center. Host PC requires Windows 10 or higher. HP Display Center is available on the Microsoft store.
- [3] Number of colors through A-FRC technology.
- [7] Host PC requires Windows 10 or higher. HP Display Center is available for download on the Microsoft store for Windows or support.hp.com for Windows and MacOS.
- [4] Included cables may vary by country.
- [8] TÜV Rheinland® 4-star eye comfort certification.
